InfiRay ZH50 Thermal Monocular

Interchangeable standard power supply for Pulsar Trail / Helion / Accolade / Digisight Ultra / Forward F.
IPS 7A is designed to extend self-contained operating time of the digital night vision riflescopes Digisight Ultra N450 / N455 LRF.

Specifications:
• Capacity: 6400 mAh
• Operating time: 10-13 h (with Helion)|
• Weight: 0.13 kg
• Dimensions: 73 x 47 x 30 mm
• Output voltage: 3.7 V
• Battery type: Li-ion

Pulsar Monocular Axion XM30F Handheld Monocular Thermal

The dynamic Axion XM30F from Pulsar is lightweight, compact and feature-packed. With a powerful 320x240 microbolometer resolution, the pocket-sized Axion XM30F detects heat signatures over 1400 yards away and transmits the images to a pristine 640x400 AMOLED Display.

Possessing 3-12x digital magnification, the Axion XM30F records .mp4 videos and is compatible with the Stream Vision 2 App, so users can capture and preserve precious outdoor memories. The Axion XM30F takes the trusted APS 3 batteries and boasts 5 hours of battery life, and is rechargeable by an external, 5-volt Micro USB. It is rated IPX7 fully-waterproof and weighs a mere .55lbs.

Whether you are hunting, hiking, checking your perimeter or just observing wildlife, the Axion XM30F is the optic of choice. It fits conveniently into a pocket or bag and can be ready-to-work at a moment’s notice. The Axion XM30F can help you make the crucial distinction between a human, wild animal, family pet or livestock. It has a built-in stadiametric rangefinder, so you always know the distance to your target, and its durable housing and IPX7 waterproof-rating mean the Axion XM30F can be used in a wide variety of weather conditions.

Features:

• 320x240 microbolometer resolution
• 12 µm pixel pitch
• 640x400 AMOLED Display
• 3-12x digital magnification
• 1420-yard detection range
• 8 color palettes
• Stadiametric rangefinder
• Built-in photo and videorecorder
• .mp4 videos
• 16GB built-in memory
• Wi-Fi connectivity
• Stream Vision 2 compatible
• Powered by APS 3 batteries
• 5 hours of battery life (rechargeable)
• Weighs .55lbs
• IPX7 fully-waterproof

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

Pulsar Axion 2 XQ35 Handheld Monocular Thermal

Pulsar’s pocket-sized thermal monocular family—the Axions—have another member – the Axion 2 XQ35! With a powerful 384x288 microbolometer that detects heat signatures over 1400 yards away, this is an excellent device for scoping large areas and locating prey. It then transmits these images to a pristine 640x400 AMOLED display, giving the user clear, crisp image of their target.

With 2-8x magnification along with built-in photo and video recording, Wi-Fi connectivity and a 16GB memory card, the Axion 2 XQ35 is a technological wonder. The Axion 2 is also supported by the Stream Vision 2 app, enabling shooters to record and preserve all their precious shooting memories.

Weighing a mere 0.6lbs, the Axion 2 XQ35 is made of a high-quality reinforced magnesium alloy that boasts IPX7 protection and operates in temperatures between -13F to 122F. Utilizing a Pulsar APS5 Li-ion battery, the Axion 2 operates for up to 11 hours.

Features

• 384x288 Microbolometer
• 1400+ yard detection range
• 640x400 AMOLED display
• Built-in photo and video recording
• Wi-Fi connectivity and Stream Vision 2 App Supported
• 8 color palettes
• IPX7 Fully Waterproof

Specifications

• Microbolometer resolution: 384x288 pixels
• Frame rate: 50 Hz
• Sensor NETD: <40 mK
• Pixel pitch: 17 µm
• Display type and resolution: AMOLED 640X400 pixels
• Built-in photo & video recorder: Yes
• Built-in memory: 16 GB
• Stream Vision 2 app support: Yes
• Magnification: 2-8x
• Digital zoom: 2/4x
• Lens focus: 35 mm
• Relative aperture: 1:1 d/f
• Field of view: 10.7 °
• Eye relief: 14 mm
• Diopter adjustment: +4/-5 .dptr
• Detection range: 1300 m
• Battery type : Pulsar APS5 Li-ion
• Battery life: 11 Hours
• External power supply: 5V (USB Type-C)
• Operating temperature: -025 to +40°С
• Level of protection: IPX7
• Dimensions: 152x50x74 mm
• Weight: 0.3 kg

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

TrackIR Pro series is Guide’s new launched handheld thermal imaging monocular designed for professional hunters. With a 640x480 IR sensor and 1280x960 HD display, it provides adaptable and excellent thermal imaging in any conditions. Support smooth zoom, built-in stadiametric rangefinder, image quality adjustment, picture-in-picture functions. At a high frame rate of 50Hz, TrackIR Pro captures sharp thermal imaging throughout dynamic and rapid motion in distance. It also supports connecting accessories to realize more functions.

Features:
• Super concealment for professional hunters: work indicator can be shut down, anti-light-leakage eyepiece, super silent button, and noiseless shutter calibration
• Excellent ergonomic design: intuitive buttons can be quickly recognised by touching even in total darkness. Modern streamlined appearance and ergonomic design, TrackIR allows you to observe the target for a long time without fatigue
• Full colour 0.4" HD display with 1280 x 960 pixels gives crisp and delicate images improving the observation comfort
• Smooth zoom
• Built-in stadiametric rangefinder: accurately measures the ranging of observed objects with known height
• User-friendly UI and powerful mobile app: the thermal monocular and app support settings such as image quality adjustment, colour palettes switching, smooth zoom, hot spot tracking Wi-Fi and more
• Multiple scene modes: seven modes of "enhance/highlight/forest/desert/snow/city/default" can be switched by one button and the image can be adaptively adjusted for different scenes to highlight the target
• IP66 rugged, durable and quality guaranteed: IP66 protection level, 1 m drop test, suitable for all kinds of harsh weather
• 6000mAh large capacity battery for longer working time
• 2 Year warranty

A fantastic alternative to Pulsar - with faster connectivity and stronger wifi to mobile signal.

View on your mobile device with the Track IR App
iOS: https://apps.apple.com/nz/app/track-ir/id1443442980
Android: https://play.google.com/store/apps/details?id=com.guideir.app&hl=en

Specifications:
• Detector Type: 640 × 480 @ 17μm, 8μm ～ 14μm, NETD ≤ 50mk
• Focal Length: 35mm/F1.0
• Focusing: Manual Focus
• FOV: 12.5° × 9.4°
• Screen: 1280×960, 0.4" Colour LCOS Display (Feel like watching 22-inch screen at 1m)
• Eyepiece: Monocular, Exit pupil≥10mm, Adjustable diopter-4~＋2
• Magnification: 2-16x
• Frame Rate: 50Hz
• Digital  Zoom 1X~8X (Smooth zoom)
• Color Palettes  White Hot, Black Hot, Red Hot 1, Red Hot 2, Red Hot 3 (track IR pro has adjustable red dot)
• Scenes Modes  Enhanced, Highlight, Forest, Desert, City, Snow, and Default (indoor)
• Picture-in-picture enlarged image is displayed on the upper left, upper-middle or upper right
• Main Functions: Photo and video, Wi-Fi, hotspot tracking, stadiametric rangefinder, image enhancement, brightness and contrast of image are adjustable, auto power-off, auto sleep, super power-save mode, the work indicator could be shut off
• Compensation Modes: Auto Compensation / Shutter Compensation / Scene Compensation
• Indicate Box: Red,/yellow/green, the coordinates of the indicate box is adjustable
• Memory Card: 16 GB
• Battery Type: Internal Li-ion battery (2x18650, 6000mAh)
• Battery Operating Time: ≥4.5h
• Video Output: Micro HDMI
• External Connection: External Connection by a Picatinny rail
• Operating Temperature: -10℃～50℃
• Storage Temperature: -30℃～60℃
• Encapsulation: IP66, 1-meter drop  test
• Weight: 560g
• Dimensions: 214mm × 65mm × 71mm
• Package Contents: Power adapter / USB cable / Micro HDMI cable / Lens cover /   Wrist strap / Lining package / Quick Start Guide

Detection Range:
• Human - 1.8m×0.5m: 1400m
• Vehicle - 2.3m×2.3m: 2800m
Recognition Range
• Human - 1.8m×0.5m: 700m
• Vehicle - 2.3m×2.3m: 1400m.

Pulsars Talion XQ38 is an exciting thermal addition to Pulsars extensive catalogue! With a 384x288 microbolometer sensor resolution, the Talion detects heat signatures up to 1475 yards! Boasting a variable magnification of 2.5-10x, the Talion expertly locates heat signatures in total darkness. The Talion features built-in photo and video recording and a multi-point prism mount to aid in exact positioning on the rifle.

The Talion has Wi-Fi integration and is supported b the Stream Vision 2 application, ensuring users can capture and preserve all their shooting memories. In a strong, but lightweight, magnesium alloy housing, the Talion has an IPX7 waterproof rating and can withstand calibers up to 12 gauge, 9.3x64 and .375 H&H.

The Talion XQ38 is an exciting, powerful thermal riflescope from Pulsar that maintains an extremely high image quality in severe weather conditions, and it functions for up to 9 hours on a single battery charge. The Talion also boasts a selection of ten reticle shapes in nine color modes, precision aiming with Picture-in-Picture mode and a large selection of different color palettes.

Features:
384×288 / 17µ / >40mK sensor
F38 f1.2 precision ground germanium objective lens
2.5x-10x magnification
9.8˚ FoV vertical @ 2.5x magnification
Quick-change APS5 battery for 10 hours operation
HD AMOLED display
Withstands 6000J recoil energy (.375H&H, 9.3×64, 12 gauge slug etc)
Waterproof IPx7 (under one meter of water for 30 mins)
Multi-point Picatinny prism mount for ease of mounting
Stream Vision 2.

Stream Vision 2 integration with IOS/Android and firmware update
Built in Wi-Fi module provides connectivity of thermal imager with Android or iOS smartphones or tablets. The smartphone and thermal imager combination offers a set of unique features such as direct image streaming, downloading and sharing recorded files, firmware update and many other.

The Guide TS450 is a thermal imaging riflescope for demanding shooters who want to shoot with extreme precision over (very) long distances. The thermal riflescope has a 3x to 13x magnification and can pick up heat sources up to 1.400m. The 50hz refresh rate makes it easy to track fast moving objects. The state-of-the-art detector in combination with an OLED display results in razor-sharp images. The TS450 comes with a separate Picatinny/Weaver mounting.

Optics and display
The thermal riflescope is equipped with a 400x300@17μ 'TEC metal encapsulated' infrared detector. The environment is displayed on an amazing 1024x768 OLED display. The 50hz refresh rate provides real-time images. The TS450 features a large 50mm lens with 3.3x magnification. You can enlarge it up to 6.6x and 13.2x with a digital zoom (and also Picture-in-Picture). You can focus on the surroundings as you like using the focus ring.

Focusing and zero setting
In order to follow targets easily and shoot with extreme precision, you can use 10 different crosshairs (see images on the right). You can set the colour of the reticle in black or white. The reticle can also be switched off. The 'zero' can easily be set and saved from the main menu. In total you can save 6 different zero settings.

Observation modes
You can select seven thermal colour pallets: White Hot, Black Hot, Red Hot 1/2/3, Green Hot and Blue Hot. Additionally, the Hot Track function allows you to "mark" the hottest object on the screen with an indicator. This makes finding and tracking targets easier than ever. You can also adjust the contrast of the environment to your own preference.

Stadiametric rangefinder
The rifle scope is equipped with a stadiametric rangefinder, which allows you to calculate the distance to an animal of known size (e.g. hare, boar or deer). This function can be used for objects with a size of 1.8m / 0.5m / 0.25m.

Reliability properties
The thermal rifle scope is resistant to recoil of 500G/1ms. The TS450 is also IP67 certified (water and dustproof and therefore suitable for all types of weather). You can power the device with one 18650 battery, which you can quickly and easily insert into the device. This allows you to use the rifle scope for up to 5 hours. A rechargeable 18650 battery and charger are included as standard.

Application Guide TS450
This thermal riflescope is ideal for hunting, shooting or airsoft. The Guide TS450 is mainly aimed at the demanding user who wants to shoot at longer distances. With the help of a video cable (included) you can display the images in real-time on a monitor. At the optional accessories you will find some waterproof, fully-certified transport cases and weapon cases.

Included:
1x Thermal Imaging Rifle Scope (50mm lens)
1x Picatinny rail mount
1x Plastic carrying case with pluck foam
1x Lens cap
1x Battery charger with EU-type AC adapter (for 2x 18650 Li-ion battery)
1x 18650 battery (2200mAh)
1x Video-out cable
1x User manual
1x Warranty certificate

Brand: Guide
Type: Monocular (for 1 eye)
Detector type: 400x300 TEC metal encapsulated (17 micron)
Display quality: 1024x768 OLED (full-color)
Thermal sensitivity: 50- 59 mm
Type connection: 0mm
Refresh Rate: Targeting, Scouting (reticle off), Picture-in-Picture (PiP)
Type of image focus: Manual Focus, Auto-focus (separate mode)
Field of view: 7,5 x 5,6 degrees
Detection distance: 1,400m
Other functionalities: Adjustable contrast, Adjustable brightness
Color palettes: White hot, Black hot, Red hot 1/2/3, Green hot, Blue hot
Usage time: 3 to 5 hours
Charging time: 50 Hz
Recording Functionality: No (but with video-out connection)
Measuring range temperature: 3,3x / 6,6x / 13,2x
Temperature accuracy: White, Black
Weight: 720 grams
Dimensions: 250 x 90 x 75mm
Mounting system: Picatinny
Power supply: 1x 18650 battery (battery + charger included)
Working Temperature: -40°C to +50°C
Water and impact resistance: IP67
Warranty: 2 years

InfiRay Rico HD RS75 Thermal Scope

The Rugged Infrared Compact Optic (RICO) HD RS75 is the first commercially available 1280x1024 resolution thermal sight ever created. You read that right, the legendary thermal image quality produced by a High Definition (1280x1024) thermal sensor is finally commercially available to night hunters in the form of an advanced thermal sight. The RICO HD RS75 has an incredible 1,310,720 pixels processed by InfiRay’s proprietary MATRIX III algorithm to create an image so clear, it is almost unbelievable.

Click here for full information

Click here for product video

Specifications:

Objective Focal Length 75mm
Eye Relief 60mm
Digital Magnification 16X
Detection Range 3600 Yards
Optical Magnification 2X
Focusing Mechanism Manual Focus
Objective F# f/1.0
Objective Diameter 75mm
Objective Lens Material Germanium
Display Type AMOLED
Diopter Range -3 - +3
Vertical Angular Field of View 9.4°
Horizontal Angular Field of View 11.7°
Display Resolution 2560×2560
Startup Time Under 10 Seconds
Reticle 7 (2 Dynamic, 5 Static)
Connector Type USB-C
User-Updatable Firmware Yes
Mobile App Yes
Storage Capacity 128GB
Connector Output Power/Data
Picture-in-Picture Yes
One-Shot Zero Yes
Stand-by Mode Yes
Rangefinder ILR-1000 LRF (Included)
External Power Source USB-C
Run Time 4+
Power Source IBP-1 Battery Pack X 2, 4+ Hours Each
Wifi Yes
Onboard Recording Video and Image
Image Capture Yes
Operating Temperature Range -4°F~122°F
Recoil Rating 1000 g/s² (300 Win./7mm Mag)
Ingress Protection IP67
Mounting Interface Picatinny STD-1913 rail
Housing Material Aluminum
Length 12.55"
Weight 44.9 Oz
Height 3.34"
Width 3.93"
Sensor Resolution 1280×1024
Spectral Response 8-12 Microns
Sensor Frame Rate 30Hz
Sensor Type InfiRay MICRO II
Sensor Pixel Size 12 micron
Thermal Sensitivity <25 mk

Pulsar Thermion 2 LRF XP50 Pro Thermal Scope with Laser Rangefinder

Pulsar’s Thermion 2 LRF XP50 PRO is a potent thermal imaging riflescope that combines a classic, sleek design with a built-in laser rangefinder. Its extremely powerful 640x480 microbolometer resolution detects heat signatures up to 2,000 yards and displays them on a crisp 1024x768 AMOLED display. With an impressive 10 hours of battery life, this thermal riflescope boasts high-precision, ambidextrous lens focusing and a variable magnification of 2x-16x. The included laser rangefinder has a range up to 875 yards, helping to illuminate and locate various targets.

Technologically advanced, the Thermion 2 LRF XP50 PRO boasts built-in photo and video recording, and it has Wi-Fi connectivity, to upload data to the Stream Vision 2 App. Further, the Thermion 2 LRF XP50 PRO can withstand calibers from 12 gauge, 9.3x64 and .375 H&H, and it is rated IPX7 completely waterproof, so you can use it in the harshest of weather conditions.

When you need a powerful thermal riflescope with a classic design and built-in laser rangefinder, few scopes can match the prowess of the Thermion 2 LRF XP50 PRO. It features 10 reticle shapes in 9 color modes, Picture-in-Picture mode and 5 unique shooting profiles.

Features:

• 640x480 microbolometer resolution
• 1024x768 AMOLED Display
• Detects heat signatures up to 2,000 yards away
• 2x-16x magnification
• Built-in photo and video recording
• Included laser rangefinder with 875-yard range
• Wi-Fi connectivity and supported by Stream Vision 2 App
• IPX7 Fully Waterproof
• 10 reticle shapes in 9 colors
• Picture-in-Picture mode
• 5 unique shooting profiles
•  Uncooled Sensor
• Withstands calibers including 12 gauge, 9.3x64 and .375 H&H

Specifications:

• Microbolometer resolution: 640x480 pixels
• Frame rate: 50 Hz
• Sensor NETD: <25 mK
• Pixel pitch: 17 µm
• Display type and resolution: AMOLED 1024x768 pixels
• Built-in photo & video recorder: Yes
• Built-in memory: 16 GB
• Stream Vision 2 app support: Yes
• Magnification: 2-16x
• Field of view(@ 100 m): 12.4/21.8 °
• Eye relief: 50 mm
• Diopter adjustment: -3/+5 .dptr
• Detection range: 1800 m
• Battery type : Pulsar APS5 Li-ion
• Battery life: 10 Hours
• External power supply: 5V to 9V (USB Type-C)
• Operating temperature: -25 to +50°С
• Level of protection: IPX7
• Dimensions: 420x78.5x94.5 mm
• Weight: 0.97 kgs
• Tube Size: 30 mm
• Shock Resistance: 6000 joules

Built-in Laser Rangefinder

• Wavelength: 905 nm
• Maximum measuring distance: 800 m
• Measurement accuracy: +/- 1 m

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

The first thermal imaging riflescope with classic design and built-in laser rangefinder

The laser rangefinder is seamlessly integrated into a slim design riflescope. The rangefinder is compact, the receiver and emitter are within clearance limits of a single optical channel. The measuring range is 800 metres – the Thermion 2 LRF provides the hunter with an accurate sense of distance at the hunting site helping to take a precise shot.

Features:
• Variable magnification
• High-precision aiming in the "Picture-in-picture" mode
• 5 individual shooting profiles / 50 zeroing distances
• A selection of 10 reticle shapes in 9 color modes
• Mounting on standard 30 mm rings
• Instant Start-up
• High caliber recoil resistance: 12 gauge, 9.3x64, .375H&H
• Completely waterproof IPX7
• Operating temperature range: -25 to +50 °C
• High contrast HD AMOLED display
• A selection of 8 color palettes
• Wide-angle eyepiece for comfortable observation
• Photo and video recording
• Stream Vision 2. WiFi integration with iOS and Android devices

Specifications:
• Sensor: 384x288 @ 17 µm (NETD <25 mK)
• Objective lens: F50 F/1.0
• Magnification: 3-12x
• Detection range: 1800 m
• Field of view (HxV), degrees / m@100m: 7.5 / 13.1
• Eye relief: 50 mm
• Type: Uncooled
• Resolution: 384x288 Pixels
• Pixel pitch: 17 µm
• NETD: <25 mK
• Frame rate: 50 Hz
• Type: AMOLED
• Resolution: 1024х768 Pixels
• Click value H/V(mm at 100 m): 13 – 3х 6.5 – 6х 3.25 – 12
• Click range H/V(mm at 100 m): 2600 / 2600
• Number of preloaded reticles: 10+
• Video / photo resolution: 1024x768 Pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16 GB
• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz
• Degree of protection, IP code (IEC60529): IPX7
• Operating temperature range: -25 – +50 °С
• Max. recoil power on rifled weapon: 6000 Joules
• Compatible mounts: Standard 30 mm Rings
• Supported Application: Stream Vision 2
• Output voltage: 3.7 V
• Battery type: Li-ion APS2
• Capacity: 4900 mAh
• Operating time on battery pack(at t=22°C): 10 hours
• External power supply: 5 V /9 V (USB Type-C Power Delivery)
• Body material: Aluminum
• Dimensions: 420 x 78.5 x 94.5 mm
• Weight: 0.97 Kg

Laser Rangefinder
• Wavelength: 905 nm
• Max. measuring range: 800 m
• Measurement accuracy: ± 1

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

The all new Pulsar Thermion 2 XQ50 PRO thermal riflescope features an all new ultra high sensitive sub 25mK NETD 384x288 17µm Lynred thermal sensor, providing a richly contrasted, crisp thermal image.

This thermal riflescope will achieve enhanced identification of animals and their extremities, and will reveal even the smallest details such as leaves, branches, and terrain in harsh weather conditions when thermal contrast is low.

Super sensitive thermal imaging sensor
Thermal imaging sensor with NETD <25mK value ensures perfect detail recognition even in the most severe weather conditions when thermal contrast is low. The smallest temperature differences in observed objects can be clearly visible during heavy rainfall, dense fog or cold mornings making it easy to recognize and identify the game and its features.

Fast aperture f1.0 germanium optics
Quality fast aperture germanium optics ensures optimal heat energy transmissivity minimizing noise and improving detail of observed scene.

Extreme detection range
High quality germanium optics coupled with an advanced thermal imaging sensor ensure an unprecedented detection range of up to 2.000 yards (1.800 metres) in, even in complete darkness.

Long battery life. Up to 10 hours on a single charge
Thermion 2 Pro riflescopes feature a unique combined battery system consisting of two rechargeable Li-ion batteries internal and external. External rechargeable battery can be hot swapped in a matter of seconds, providing additional time during the hunt.

Wi-Fi integration with iOS and Android devices. Stream Vision 2 application.
The built-in Wi-Fi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless update of the device software, transmission of images to the screen of a mobile device in real time, remote control of digital functions of the device and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.

Recoil Rated up to .375 H&H, 12-Gauge and 9.3x64
Recoil rated up to 6,000 joules for flawless performance on larger calibers up to .375 H&H, 12-gauge and 9.3x64.

Variable magnification
The base magnification of Thermion 2 Pro riflescopes can be increased by means of digital zoom. Zoom changes either gradually in 2x steps or continuously offering the ideal ratio of magnification and visible field of view for specific situations.

Enhanced Wi-Fi connectivity with 2.4 / 5 GHz waveband support
In Thermion 2 PRO thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz Wi-Fi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.

Zeroing profiles management
Store up to 5 zeroing profiles, with 10 distance coordinates each for varying situations, in internal memory for quick rifle change-outs and on-the-fly adjustments.

A selection of 10 reticle shapes in 9 colour modes
Thermions possess a wide array of shape and color customizable reticles, including static, ballistic and scalable reticles. 9 Color options help to optimize aiming for specific conditions.

Photo and video recording
Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording a video. 16 GB of internal memory will give the ability to record many hours of video and tens of thousands of photos.

High-precision aiming in the «Picture-in-picture» mode
The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.

High contrast HD AMOLED display
1024x768 HD AMOLED display has enhanced color rendering, power saving, a high contrast image and quick-response, providing clear and smooth images for on-the-move observation or in cold conditions.

A selection of 8 colour palettes
A choice of 8 colour palettes lets the user observe their field of view more effectively, allowing them to optimise the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are most suitable for long observation in the night.

Completely waterproof IPX7
With an IPX7 waterproof rating, the Thermion 2 PRO riflescopes work in conditions of high humidity and heavy rain and can withstand half an hour immersion in water to a depth of 1 meter.

Specifications:

Sensor    384x288 pix. @ 17 µm (NETD <25 mK)
Objective lens    F50 F/1.0
Magnification, x    3-12
Field of view (HxV), degrees / m@100m    7.5/13.1
Detection range, m    1850
Sensor Type    uncooled
Resolution, pixels    384x288
Pixel pitch, µm    17
NETD, mK    <25
Frame rate, Hz    50
Eye relief, mm    50
Display Type    AMOLED
Resolution, pixels    1024х768
Click value, H/V, mm at 100 m    18 – 2.5x, 9 – 5x, 4.5 – 10x
Click range, H/V, mm at 100 m    3600/3600
Number of preloaded reticles    10
Video / photo resolution, pixel    1024x768
Video / photo format    .mp4 / .jpg
Built-in memory, GB    16
Wireless Protocol    Wi-Fi
Wireless Standard    802.11 b/g/n/ac
Frequency, GHz    2.4 / 5 GHz
Degree of protection, IP code (IEC60529)    IPX7
Operating temperature range, °С    -25 – +50
Max. recoil power on rifle (Eo), Joules    6000
Shock resistance on the smooth-bore rifles, caliber    12
Compatible mounts    Standard 30 mm rings
Supported Application    Stream Vision 2
Output voltage, V    3.0–4.2
Li-Ion Battery Pack АPS2 (external), Li-Ion Battery Pack APS3 (external)-sold separately*, Li-Ion Battery Pack APS5 (internal)
Capacity, mAh    2000 (external) + 3200 (external)* + 4900 (internal)
Operating time on battery pack (at t=22°C), h *    10
External power supply, V    5 V, 9 V (USB Type-C Power Delivery)
Body material    Metal
Dimensions, mm    412х78х83
Weight, kg    0,9
SKU (Model #)    76548

Clip CH50W is a top-end front attachment designed as the infrared expansion device of the day scope. In addition to retaining the advantages of clear image quality and no need to re-zero, CH50W also adds Wifi, photo and video functions. CH50W is featuring with precise aiming, ultra-clear imaging and complete functions. Start your adventure with CH50W, turning your day riflescopes into powerful thermal imaging aiming systems.

The unit adopts a 12μm 640×512 resolution thermal sensor with NETD ≤40mK and a 1024×768 OLED display to bring an innovative improvement in thermal imaging quality which ensures perfect detailed recognition even in the hardest weather conditions.

The built-in ultra-clear mode brings a more detailed view and enhanced object recognition, makes the image more delicate.

With the special calibration of the CH50W, there is no need to re-zero after mounting to the day scope. Clamp and Shoot, that's it.

CH50W supports gun-type selection corresponding to different UI interface switching, which is better compatible with day sights with different magnification ranges.

G1 and G2 are recommended magnification of the day sight for 1×-4×, while G3 and G4 for 5×-9×.

Clip CH50W features a simple connector arranged to make the hunt easier on set. The Bluetooth remote controls are very straightforward and almost identical to their predecessor which put the operation of the CH50W at your fingertips.

With IAR-adapter mounts, the durable and compact CH50W can be easily attached to or detached from day optics in seconds to set up for handheld or mounted devices, so you can focus on shooting, not the imager.

The CH50W supports Wifi, photo and video functions. The onboard 32GB internal memory handles recoil flawlessly and stores hours of video or thousands of photos.

Specifications:

• Model CH50W
• Detector Type VOx Uncooled
• Resolution 640×512
• Pixel Size, μm 12
• NETD, mK ≤40
• Frame Rate, Hz 50
• Objective Lens, mm 50
• Field of View 8.8°×7.0°
• E-zoom ×1/×2/×4
• Detection Range, 2597m (Target size: 1.7m×0.5m, P(n)=99%)
• Display 1024×768 OLED
• Battery CR123×2/16650x2
• Max. Battery Life, h 4/7
• USB Interface Type-C
• IP Rating IP66
• Remote Control Bluetooth
• Amount of built-in memory, GB 32
• Weight (without batteries) , g＜590
• Dimension, mm 175×74×68
• Adapter Ring M52×0.75

Zoom ZH50 is a high-end thermal imaging monocular for outdoor. It has greater magnification and keeps three unique technologies of ZOOM series: Dual Field of View, 1440×1080 HD Resolution and Shutterless Calibration Technology.

With the ZOOM’s patented dual-field-of-view design, observers can seamlessly switch between a wide field-of-view (FOV) for detection, and a narrow FOV for target identification. It could be extensively used for night hunting, observation and terrain positioning, search, rescue, and more.

The wider FOV with a focal length of 25mm can be used for target search while the narrower FOV with a focal length of 50mm can be used for target identification.

The detection distance can reach up to 2.6km. With F-number 0.88/1.1, imaging clarity can be lifted to a new level.

Using 1440×1080 FHD OLED display, the observation effect is more excellent. And the 20×magnification eyepiece makes the target search more accurate and the observation distance is longer.

The shutterless core module is adopted to nullify the shutter calibration, simplify the operation.

ZH50 is equipped with uncooled VOx 12um 640×512 high resolution sensor featuring NETD ≤25mk (25°C, F#=1.0). With the powerful sensor and image algorithm, better image quality is provided. Even in heavy fog and rain, the built-in ultra clear mode can also result in clear imaging through a more detailed field of view and enhanced object identification capabilities.

Using low-power components, lower power consumption, with a standard additional battery pack and a replaceable 4400mAh large-capacity lithium battery pack, battery life up to 20 hours.

ZH50 is built with memory of 32GB which can support to store video and pictures. Built-in WiFi module supports APP connection and media transmission.

For different hunting environments and personal habits, ZH50 provides more than 5 color palettes, including “white hot” “black hot” “red hot” “color” and “hot target highlight”.  Switching between different color palettes is fast and easy.

Specifications:

• ZOOM Series    ZH50
• Detector    Type    Uncooled VOx
• Resolution    640×512
• Pixel    12μm
• NETD    ≤25mK
• Frame Rate    50hz
• Optical    Objective Focal Length    25/50mm    19/38mm
• F-number    0.88/1.1
• Magnification    2.2x ~ 17.6x
• Digital Zoom    1x/2x/3x/4x
• Exit Pupil Distance    20mm
• Exit Pupil Diameter    5.5mm
• Diopter    -5 ~ +5
• Display    Type    AMOLED
• Resolution    1440×1080
• Dimension    0.4″
• Battery    Type    Lithium-ion
• Capacity    4400mAh
• Service Voltage    3V~4.2V
• External Voltage    5V (Type C USB)
• Physical Specs    Operating Time    10h
• Internal Storage    32GB
• Operating Temperature    -20℃~+50℃
• Weight    650g
• Dimension    195×65×60 (mm)
