Pulsar APS 5 Battery Charger

The Pulsar Thermion 2 LRF XL50 offers the highest level of thermal imaging. The image generated with the new 1024x768- pixel thermal sensor features high definition and rich detail ideal for uncompromised trophy identification. The silhouettes, anatomy & behavioural peculiarities of the animal are clearly visible and easily distinguished.

Extreme image detail on high zoom

Variable 1.75-14x magnification (x8 digital zoom) provides improved focus and better overall object recognition at significant distances. The HD-sensor allows to maintain a high level of image detail across the whole magnification range. The zoom changes either gradually in 2x step or continuously for a customized FOV / magnification ratio for each specific situation.

Precise laser range finding

Understanding the target distance is an essential factor in making the right decisions. The compact laser rangefinder with a range of up to 800 metres is seamlessly integrated into a slim design riflescope, the receiver and emitter are within clearance limits of a single optical channel.

Integrated ballistic calculator for long-range shooting

Thermion 2 LRF ensures accurate shooting at any distance. The built-in laser rangefinder provides the hunter with an exact sense of distance to the target while the sophisticated internal ballistics algorithm calculates the suggested POA for accurate long-range shooting. Simply create a ballistic profile for your shooting equipment, upload it to the Thermion's memory with the Stream Vision Ballistics App, and turn your Thermion 2 LRF XL50 into a highly accurate and efficient long-range aiming tool.

Wide field of view for easy scanning

Thermion 2 LRF XL50 offers a wide field of view for easy scanning and spotting. Even at high zoom levels, the large-format sensor allows for a well-balanced FOV / magnification ratio.

Premium HD-class germanium optics

For a clear and detailed image field of view, the Thermion's 2 LRF XL50 germanium F50/1.0 objective lens truly expands the advantages of an HD thermal sensor. The use of aspherical lenses and diffractive optical elements maintains a high aperture ratio with the capability of sharp and precise image projection across the entire sensor area.

High-precision ambidextrous lens focusing

Objective lens with internal focusing mechanism gives a clear and sharp image at any range. Ergonomic focusing wheels are located on the right and left sides, making focusing easy either left- or right-handed.

Ground-breaking image processing

The pixel-to-pixel image transfer from the sensor to the display makes the image as sharp as possible. Adjustable sensor sensitivity amplification combined with new filtration algorithms offers the hunter great opportunities for observation in diverse weather and temperature conditions. The amplification setting helps to define the animal’s trophy features and ensures clear rendering of objects and background in the field of view.

Wireless remote control included

The Pulsar BT wireless Bluetooth remote control completely duplicates the regular buttons. The remote control features excellent ergonomics − the buttons activate the most used functions, while rotating or pressing the encoder operates fine adjustment and menu navigation. The design, size and positioning of the buttons and encoder are customized for use with both bare hands and gloved hands. It takes minimum movement for a hunter to control the riflescope enabling them to maintain maximum concentration on the hunting process with the remote control placed in any convenient position on the fore-end or rifle butt.

Mounting on standard 30 mm rings

The Thermion 2 LRF XL50 offers visual aesthetics on any hunting weapon. From the outside the riflescope resembles a classic day sight in a 30mm aluminum alloy housing. This form factor provides flexibility for mounting the scope on hunting weapons using proven ring solutions.

.375H&H ready

Thermion 2 LRF XL50 thermal riflescope is high impact resistant and can be used with rifled hunting weapons with calibers of 9.3x64, .30-06, .300, .375H&H, etc., as well as with smooth-bore and pneumatic weapons.

10 shooting profiles / 100 zeroing distances

Zeroing settings are saved in a shooting profile. The Thermion 2 LRF XL50 memory contains up to 10 shooting profiles for several types of weapons or cartridges. Each profile holds up to 10 zeroing distances input manually, but can be transformed for automatic ballistic calculations based on measured distance using the Stream Vision ballistics app.

A selection of 10 reticle shapes in 9 color modes

A reticle is electronically displayed in the same plane as the target. The Thermion 2 LRF XL50 memory contains ten reticle configurations and functions (direct shot type, ballistic, scalable and regular), all available in nine colors.

High-precision aiming in the «Picture-in-picture» mode

The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.

Customizable user mode for individual image adjustment

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

Combined dual battery system

The Thermion 2 LRF XL50 is powered with two rechargeable batteries: one built-in with a capacity of 4.9 A·h, and the other replaceable. The standard package supply includes replaceable batteries of 2A·h and 3.2 A·h capacity. A single charge guarantees up to 10 hours of continuous operating time. The embossing on the body of the replaceable batteries enables accurate determination of the correct position and enables replacing a flat battery with a new one quickly and confidently in complete darkness by touch alone.

64 GB memory photo and video recording

Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording a video. 64 GB of internal memory gives the ability to record many hours of video and tens of thousands of photos.

Flexible set of colour palettes for various needs

1024x768 HD AMOLED display has enhanced color rendering, power saving, a high contrast image and quick-response, providing clear and smooth images for on-the-move observation or in cold conditions. A choice of 8 colour palettes lets the users observe their field of view more effectively, allowing them to optimise the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are most suitable for long observation in the night.

Wi-Fi integration with iOS and Android devices

The built-in Wi-Fi module with a dual 2.4 / 5 GHz waveband support connects the riflescope with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless update of the device software, transmission of images to the screen of a mobile device in real time, remote control of digital functions of the device and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a thermal imaging device.

Operation in extreme temperatures -25 to +50°C

Thermion 2 LRF riflescopes are designed to operate in a wide range of temperatures -25 to +50 °C. The frost-resistant AMOLED display has a standout quick response time and ensures a sharp image when observed in motion.

IPX7 submersion waterproof rated

With an IPX7 waterproof rating, the Thermion 2 LRF XL50 riflescope works in conditions of high humidity and heavy rain and can withstand half an hour immersion in water to a depth of 1 meter.

Specifications:

Main

• Sensor: 1024x768 @ 12 µm (NETD <35 mK)
• Objective lens: F50 / 1.0
• Magnification: 1.75 – 14x
• Field of view (HxV): 14x10.5 / 24.6x18.4 degrees / m@100m
• Detection range: 2300m

Sensor

• Type: uncooled
• Resolution: 1024x768 pixels
• Pixel pitch: 12 µm
• NETD: 35 mK
• Frame rate: 50Hz

Optics

• Objective lens: F50 / 1.0
• Magnification: 1.75 – 14
• Field of view (HxV): 14x10.5 / 24.6x18.4 degrees / m @ 100 m
• Eye relief: 50mm

Display

• Type: AMOLED
• Resolution: 1024x768 pixels

Range Performance

• Detection range: 2300m

Laser Rangefinder

• Safety class for laser equipment according to IEC 60825-1:2014: 1
• Wavelength: 905nm
• Max. measuring range: 800m
• Measurement accuracy: ± 1m

Reticle

• Click value, H/V, mm at 100 m: 24 – 1.75х, 12 – 3.5х, 6 – 7х, 3 – 14х
• Click range, H/V, mm at 100 m: 4800 / 4800
• Number of preloaded reticles: 10

Video Recorder

• Video / photo resolution: 1024x768 pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 64 GB

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz

Bluetooth

• Wireless Protocol: BLE 4.2
• Wireless Standard: IEEE 802.15.1
• Frequency: 2.4 GHz

Environmental Characteristics

• Degree of protection IP code (IEC60529): IPХ7 (waterproof)
• Operating temperature range: -25 – +50°С

Connections and Compatibilities

• Max. recoil power on rifled weapon (Eo): 6000 Joules
• Shock resistance on the smooth-bore rifles: caliber 12
• Compatible mounts: Standard 30 mm rings
• Supported Application: Stream Vision 2, Stream Vision Ballistics

Power Supply

• Output voltage: 3.0 – 4.2 V
• Battery type: Dual Li-Ion B-Pack Mini Power System: 2 A·h Changeable Battery (external) / 4.9 A·h Battery (internal)
• Capacity: 2000 (external) + 4900 (internal) mAh
• Operating time on battery pack (at t=22°C), h * : 7
• External power supply: 5V, 9V (USB Type-C Power Delivery)

Weight & Size

• Body material: Aluminum alloy
• Dimensions: 426 x 78.5 x 94.5mm
• Weight: 1.03kg

Pulsar Thermion 2 LRF XP50 Pro Thermal Scope with Laser Rangefinder

Pulsar’s Thermion 2 LRF XP50 PRO is a potent thermal imaging riflescope that combines a classic, sleek design with a built-in laser rangefinder. Its extremely powerful 640x480 microbolometer resolution detects heat signatures up to 2,000 yards and displays them on a crisp 1024x768 AMOLED display. With an impressive 10 hours of battery life, this thermal riflescope boasts high-precision, ambidextrous lens focusing and a variable magnification of 2x-16x. The included laser rangefinder has a range up to 875 yards, helping to illuminate and locate various targets.

Technologically advanced, the Thermion 2 LRF XP50 PRO boasts built-in photo and video recording, and it has Wi-Fi connectivity, to upload data to the Stream Vision 2 App. Further, the Thermion 2 LRF XP50 PRO can withstand calibers from 12 gauge, 9.3x64 and .375 H&H, and it is rated IPX7 completely waterproof, so you can use it in the harshest of weather conditions.

When you need a powerful thermal riflescope with a classic design and built-in laser rangefinder, few scopes can match the prowess of the Thermion 2 LRF XP50 PRO. It features 10 reticle shapes in 9 color modes, Picture-in-Picture mode and 5 unique shooting profiles.

Features:

• 640x480 microbolometer resolution
• 1024x768 AMOLED Display
• Detects heat signatures up to 2,000 yards away
• 2x-16x magnification
• Built-in photo and video recording
• Included laser rangefinder with 875-yard range
• Wi-Fi connectivity and supported by Stream Vision 2 App
• IPX7 Fully Waterproof
• 10 reticle shapes in 9 colors
• Picture-in-Picture mode
• 5 unique shooting profiles
•  Uncooled Sensor
• Withstands calibers including 12 gauge, 9.3x64 and .375 H&H

Specifications:

• Microbolometer resolution: 640x480 pixels
• Frame rate: 50 Hz
• Sensor NETD: <25 mK
• Pixel pitch: 17 µm
• Display type and resolution: AMOLED 1024x768 pixels
• Built-in photo & video recorder: Yes
• Built-in memory: 16 GB
• Stream Vision 2 app support: Yes
• Magnification: 2-16x
• Field of view(@ 100 m): 12.4/21.8 °
• Eye relief: 50 mm
• Diopter adjustment: -3/+5 .dptr
• Detection range: 1800 m
• Battery type : Pulsar APS5 Li-ion
• Battery life: 10 Hours
• External power supply: 5V to 9V (USB Type-C)
• Operating temperature: -25 to +50°С
• Level of protection: IPX7
• Dimensions: 420x78.5x94.5 mm
• Weight: 0.97 kgs
• Tube Size: 30 mm
• Shock Resistance: 6000 joules

Built-in Laser Rangefinder

• Wavelength: 905 nm
• Maximum measuring distance: 800 m
• Measurement accuracy: +/- 1 m

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

Pulsar is once again at the forefront of innovation with the Thermion Duo DXP50. The world’s first multispectral hunting riflescope, the Thermion Duo combines the high-tech thermal imaging Pulsar is known for with the clarity and vividness of a full-color daytime optic.

Designed primarily for hunting, the Thermion Duo DXP50 has a detection range of 1800 yards. This highly versatile multispectral optic can defeat animal camouflage and fog on thermal mode and judge a prey’s trophy qualities in daylight with its full color mode. With its picture-in-picture feature, a hunter can simultaneously find an animal through dense fog or foliage with its 640x480 high-sensitivity thermal sensor while observing the area around it in full color 4k HD.

The Thermion Duo DXP50 boasts the wide range of practical features Pulsar products are known for, including one-shot freeze zeroing, 1024x768 photo and video recording with audio, Wi-Fi integration with the Stream Vision 2 app, and advanced image processing.

With six hours of battery life and compatibility with USB C chargers, the Thermion Duo DXP50 is both powerful and long-lasting. With its solid aluminum alloy construction, the Thermion Duo DXP50 is both shockproof and waterproof, with an IPX7 rating, capable of withstanding the most rigorous wilderness conditions. With its range of features and capabilities, the Thermion Duo DXP50 represents the future of hunting and digital optics.

Features:

• The first multispectral Pulsar hunting riflescope
• Day & night use
• 4K full-color sensor for daytime hunting
• 640x480 @ NETD < 25 mK high-sensitivity thermal imaging sensor
• Fast aperture F50/1.0 thermal lens
• Advanced image processing: enhanced detail, clarity and contrast
• Combined multispectral viewing modes
• One-shot freeze zeroing in thermal and digital channels
• 1800m thermal detection range day & night
• Full featured: video recording, Wi-Fi, Stream Vision 2 mobile app compatibility

Specifications:

• Model: DXP50
• SKU: 76571

Microbolometer

• Type: uncooled
• Resolution, pixels: 640x480
• Pixel Pitch, µm: 17
• NETD, mK: < 25
• Frame refresh rate, Hz: 50

Digital Sensor

• Type: CMOS
• Resolution, pixels: 3840x2160

Optical Specifications

• Lens, mm: Thermal imaging channel: F50 F/1.0
• Lens Digital channel: F17 F/4.34 (non-focusing lens)
• Magnification, x: 2-16
• Eye relief, mm/inch: 50/1.96
• Field of view (H), °/m@100: 12,4/21,8
• Diopter adjustment, D: -3/+5
• Detection distance (Thermal imaging channel, object of "deer" type), m/y: 1800/1968.5

Aiming Reticle

• Click value (H/V), mm@100 m – when magnifying, x: 21.3 – 2х, 10.7 – 4х, 5.3 – 8х, 2.7 – 16х
• Click range, mm@100 m (H/V): 4250/4250

Display

• Type: AMOLED
• Resolution, pixels: 1024х768

Operating Features

• Diameter of the riflescope body to assemble the mounting rings, mm: 30
• Power Supply, V: 3–4.2
• Battery Packs (built-in APS5 and removable APS2) operating time at temp. = 22 °C, hrs**: 6
• Max. recoil power on rifled firearm, Joules: 6000
• Max. recoil power on smoothbore firearm, caliber" 12
• Degree of protection IP code (IEC60529): IPX7
• Operating temperature, °С / °F: -25 – +50 / -13 – +122
• Dimensions with an eyecup, mm/inch: 420x78x83.5 / 16.54x3.07x3.29
• Weight (with APS2 battery), kg/oz: 0.96 / 33.86

Video Recorder

• Photo / video resolution, pixels: 1024x768
• Video / photo format: .mp4 / .jpg
• Built-in memory: eMMC 16 GB

Wi-Fi Channel***

• Frequency: 2.4/5 GHz
• Standard: IEEE 802.11 b/g/n/ac

The Telos XP50 stands as an extremely powerful optic. With an industry-leading <18mK NETD sensor and enhanced image processing algorithms, this extremely powerful thermal monocular gives users highly refined details, even in the toughest conditions.

For the first time in a Pulsar product, the Telos XP50’s adjustment rings allow users to gradually zoom in and focus in one fluid motion. This fine camera-like digital control system allows smooth magnification adjustments and pristine quality even at high magnifications. Its built-in laser rangefinder has a range of 1000 Metres – helping users survey areas and target objects within a practical accuracy of 1 Metre.

Further enhancing its long-range viewing abilities, the Telos XP50 has a detection range of more than 1,800 Metres, capable of detecting human-sized heat sources in the harshest weather.

The Telos XP50 pro is also built to last. From arctic conditions to wetland swamps, this unit continuously provides reliable heat detection. With a temperature resistance of -25 to +40°C the Telos is built to withstand different environments, hot or cold.

Outfitted with a brand new LPS 7i quick-charge Lithium-ion battery, the Telos has more than 8.5 hours of battery life and can be charged with any USB-C compatible charging device, including common cellphone chargers. The LPS 7i also supports wireless charging.

Designed for longevity and crafted with care and precision, Pulsar’s Telos XP50 is the only thermal monocular you will ever need.

Features

• Highly sensitive thermal sensor
• Advanced Pulsar Image Boost technology
• Objective ring zoom control
• Built for the toughest conditions
• Replaceable battery pack with direct plug & wireless fast charge options
• Ergonomic, nonslip rubber-coated housing
• Adaptable for left- and right-handed use
• Ergonomic and functional carrying case
• User Mode saves selected brightness and contrast settings
• 1000 m range for LRF (Laser Range Finder)
• 1800 m Thermal detection range
• Stream Vision 2. Wi-Fi integration with iOS and Android devices
• Fast aperture F50/1.0 germanium lens
• High-contrast AMOLED display
• IPX7 submersion waterproof-rated
• Built-in video recorder with 64GB internal memory
• A selection of 8 colour palettes

Main

• Sensor: 640x480 pix. @ 17 µm (NETD <18 mK)
• Objective lens: F50 / 1.0
• Magnification: 2.5 – 10x (x4 zoom)
• Field of view (HxV), degrees / m @100m: 12.4x9.3° / 21.8x16.3°
• Eye relief: 14 mm
• Detection range: 1800 m
• Operating time on battery pack (at t=22°C): 8.5 Hours
• Sensor
• Type: uncooled
• Resolution: 640x480 p
• Pixel pitch: 17 µm
• NETD: <18 mK

Display

• Type: AMOLED HD
• Resolution: 1024x768 p
• Frame rate: 50Hz

Video Recorder

• Video / photo resolution: 1024x768p
• Video / photo format: .mp4 / .jpg
• Built-in memory,: 64 gb

Laser Rangefinder

• Safety class for laser equipment according to IEC 60825-1:2014: 1
• Wavelength: 905 nm
• Max. measuring range: 1000 m
• Measurement accuracy: ± 1 m

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 Ghz

Environmental Characteristics

•  Degree of protection, IP code (IEC60529): IPХ7 (waterproof)
• Operating temperature range: -25 – +40 °С

Connections and Compatibilities

• Mount Type: 1/4"
• Supported Application: Stream Vision 2

Power Supply

• Output voltage: 3.0 – 4.2 V
•  Battery type: LPS 7i Li-Ion Battery Pack
• Capacity: 6400 mAh
• Operating time on battery pack (at t=22°C): 8.5 Hours
• External power supply: 5V & 9V (USB Type-C Power Delivery)

Weight & Size

• Body material: Rubber armoured reinforced plastic
• Dimensions: 238 x 72 x 90 mm
• Weight: 720 grams

The first thermal imaging riflescope with classic design and built-in laser rangefinder

The laser rangefinder is seamlessly integrated into a slim design riflescope. The rangefinder is compact, the receiver and emitter are within clearance limits of a single optical channel. The measuring range is 800 metres – the Thermion 2 LRF provides the hunter with an accurate sense of distance at the hunting site helping to take a precise shot.

Features:
• Variable magnification
• High-precision aiming in the "Picture-in-picture" mode
• 5 individual shooting profiles / 50 zeroing distances
• A selection of 10 reticle shapes in 9 color modes
• Mounting on standard 30 mm rings
• Instant Start-up
• High caliber recoil resistance: 12 gauge, 9.3x64, .375H&H
• Completely waterproof IPX7
• Operating temperature range: -25 to +50 °C
• High contrast HD AMOLED display
• A selection of 8 color palettes
• Wide-angle eyepiece for comfortable observation
• Photo and video recording
• Stream Vision 2. WiFi integration with iOS and Android devices

Specifications:
• Sensor: 384x288 @ 17 µm (NETD <25 mK)
• Objective lens: F50 F/1.0
• Magnification: 3-12x
• Detection range: 1800 m
• Field of view (HxV), degrees / m@100m: 7.5 / 13.1
• Eye relief: 50 mm
• Type: Uncooled
• Resolution: 384x288 Pixels
• Pixel pitch: 17 µm
• NETD: <25 mK
• Frame rate: 50 Hz
• Type: AMOLED
• Resolution: 1024х768 Pixels
• Click value H/V(mm at 100 m): 13 – 3х 6.5 – 6х 3.25 – 12
• Click range H/V(mm at 100 m): 2600 / 2600
• Number of preloaded reticles: 10+
• Video / photo resolution: 1024x768 Pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16 GB
• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz
• Degree of protection, IP code (IEC60529): IPX7
• Operating temperature range: -25 – +50 °С
• Max. recoil power on rifled weapon: 6000 Joules
• Compatible mounts: Standard 30 mm Rings
• Supported Application: Stream Vision 2
• Output voltage: 3.7 V
• Battery type: Li-ion APS2
• Capacity: 4900 mAh
• Operating time on battery pack(at t=22°C): 10 hours
• External power supply: 5 V /9 V (USB Type-C Power Delivery)
• Body material: Aluminum
• Dimensions: 420 x 78.5 x 94.5 mm
• Weight: 0.97 Kg

Laser Rangefinder
• Wavelength: 905 nm
• Max. measuring range: 800 m
• Measurement accuracy: ± 1

Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty
• InfiRay: 2 Year warranty: https://www.infiray.com/uploads/file/after-sales-service-policy.pdf

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period that what is specified for the units above. The warranty does not cover mis-use or accidental damage caused by the operator.

Pulsar’s Talion XG35 offers the most advanced features the Talion family has to offer. With its 640x480 microbolometer sensor resolution and 12μm pixel pitch, the XG35 offers unparalleled thermal imagery with 2-16x magnification and a detection range of 1,914 yards.

Its 1024x768 AMOLED display provides a crystal clear display, allowing hunters to see their environment in high definition, while any hunting memories can be preserved using the Talion XG35’s built-in photo and video recording software, which works in conjunction with integrated Wi-Fi and the Stream Vision 2 app.

Rugged and dependable, the Talion XG35 is built with a strong, lightweight aluminum housing and is recoil rated for calibers up to 12ga and .375 H&H. Its IPX7 waterproof rating, protecting it against rain and water immersion for short periods of time.

The Talion XG35 is powered by a Pulsar APS5T rechargeable battery, giving the unit 7 hours of battery life on a single charge, more than enough time to complete a hunt. The Talion also boasts a selection of ten reticle shapes in nine color modes, precision aiming with Picture-in-Picture mode and a large selection of different color palettes, making it a versatile shooting tool for all environmental conditions.

Features:

Specifications:

Sensor

• Type: uncooled
• Resolution, pixels    640x480 pixels
• Pixel pitch: 12 µm
• NETD: < 40 mK
• Frame rate: 50 Hz

Optics

• Objective lens: F35 / 1.0
• Magnification:  2 – 16x
• Field of view (HxV): 12.5x9.4 / 21.9x16.5 degrees / m @ 100 m
• Eye relief: 50 mm
• DisplayType: AMOLED
• Resolution: 1024х768 pixels

Range Performance

• Detection range: 1750 m

Reticle

• Click value: 21 / 21 (on minimum magnification) H/V, mm at 100 m
• Click range: 4200 / 4200 H/V, mm at 100 m
• Number of preloaded reticles: -

Video Recorder

• Video / photo resolution: 1024x768 pixel
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16 GB

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz

Environmental Characteristics

• Degree of protection: IPX7
• Operating temperature range: -25 – +50 °С

Connections and Compatibilities

• Max. recoil power on rifled weapon (Eo): 6000 Joules
• Shock resistance on the smooth-bore rifles, caliber: 12
• Compatible mounts: Weaver U Mount, Weaver USQD Mount, Weaver LQD Mount
• Supported Application: Stream Vision 2

Power Supply

• Output voltage: 3.0 – 4.2 V
• Battery type: APS 5T
• Capacity: 4900 mAh
• Operating time on battery pack (at t=22°C), h *: 7
• External power supply: 5 V, 9 V (USB Type-C Power Delivery)

Weight & Size

• Body material: Magnesium alloy
• Dimensions: 330x57x67
• Weight: 0.7 kg (without APS 5T battery)

The all new Pulsar Thermion 2 XQ50 PRO thermal riflescope features an all new ultra high sensitive sub 25mK NETD 384x288 17µm Lynred thermal sensor, providing a richly contrasted, crisp thermal image.

This thermal riflescope will achieve enhanced identification of animals and their extremities, and will reveal even the smallest details such as leaves, branches, and terrain in harsh weather conditions when thermal contrast is low.

Super sensitive thermal imaging sensor
Thermal imaging sensor with NETD <25mK value ensures perfect detail recognition even in the most severe weather conditions when thermal contrast is low. The smallest temperature differences in observed objects can be clearly visible during heavy rainfall, dense fog or cold mornings making it easy to recognize and identify the game and its features.

Fast aperture f1.0 germanium optics
Quality fast aperture germanium optics ensures optimal heat energy transmissivity minimizing noise and improving detail of observed scene.

Extreme detection range
High quality germanium optics coupled with an advanced thermal imaging sensor ensure an unprecedented detection range of up to 2.000 yards (1.800 metres) in, even in complete darkness.

Long battery life. Up to 10 hours on a single charge
Thermion 2 Pro riflescopes feature a unique combined battery system consisting of two rechargeable Li-ion batteries internal and external. External rechargeable battery can be hot swapped in a matter of seconds, providing additional time during the hunt.

Wi-Fi integration with iOS and Android devices. Stream Vision 2 application.
The built-in Wi-Fi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless update of the device software, transmission of images to the screen of a mobile device in real time, remote control of digital functions of the device and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.

Recoil Rated up to .375 H&H, 12-Gauge and 9.3x64
Recoil rated up to 6,000 joules for flawless performance on larger calibers up to .375 H&H, 12-gauge and 9.3x64.

Variable magnification
The base magnification of Thermion 2 Pro riflescopes can be increased by means of digital zoom. Zoom changes either gradually in 2x steps or continuously offering the ideal ratio of magnification and visible field of view for specific situations.

Enhanced Wi-Fi connectivity with 2.4 / 5 GHz waveband support
In Thermion 2 PRO thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz Wi-Fi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.

Zeroing profiles management
Store up to 5 zeroing profiles, with 10 distance coordinates each for varying situations, in internal memory for quick rifle change-outs and on-the-fly adjustments.

A selection of 10 reticle shapes in 9 colour modes
Thermions possess a wide array of shape and color customizable reticles, including static, ballistic and scalable reticles. 9 Color options help to optimize aiming for specific conditions.

Photo and video recording
Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording a video. 16 GB of internal memory will give the ability to record many hours of video and tens of thousands of photos.

High-precision aiming in the «Picture-in-picture» mode
The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.

High contrast HD AMOLED display
1024x768 HD AMOLED display has enhanced color rendering, power saving, a high contrast image and quick-response, providing clear and smooth images for on-the-move observation or in cold conditions.

A selection of 8 colour palettes
A choice of 8 colour palettes lets the user observe their field of view more effectively, allowing them to optimise the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are most suitable for long observation in the night.

Completely waterproof IPX7
With an IPX7 waterproof rating, the Thermion 2 PRO riflescopes work in conditions of high humidity and heavy rain and can withstand half an hour immersion in water to a depth of 1 meter.

Specifications:

Sensor    384x288 pix. @ 17 µm (NETD <25 mK)
Objective lens    F50 F/1.0
Magnification, x    3-12
Field of view (HxV), degrees / m@100m    7.5/13.1
Detection range, m    1850
Sensor Type    uncooled
Resolution, pixels    384x288
Pixel pitch, µm    17
NETD, mK    <25
Frame rate, Hz    50
Eye relief, mm    50
Display Type    AMOLED
Resolution, pixels    1024х768
Click value, H/V, mm at 100 m    18 – 2.5x, 9 – 5x, 4.5 – 10x
Click range, H/V, mm at 100 m    3600/3600
Number of preloaded reticles    10
Video / photo resolution, pixel    1024x768
Video / photo format    .mp4 / .jpg
Built-in memory, GB    16
Wireless Protocol    Wi-Fi
Wireless Standard    802.11 b/g/n/ac
Frequency, GHz    2.4 / 5 GHz
Degree of protection, IP code (IEC60529)    IPX7
Operating temperature range, °С    -25 – +50
Max. recoil power on rifle (Eo), Joules    6000
Shock resistance on the smooth-bore rifles, caliber    12
Compatible mounts    Standard 30 mm rings
Supported Application    Stream Vision 2
Output voltage, V    3.0–4.2
Li-Ion Battery Pack АPS2 (external), Li-Ion Battery Pack APS3 (external)-sold separately*, Li-Ion Battery Pack APS5 (internal)
Capacity, mAh    2000 (external) + 3200 (external)* + 4900 (internal)
Operating time on battery pack (at t=22°C), h *    10
External power supply, V    5 V, 9 V (USB Type-C Power Delivery)
Body material    Metal
Dimensions, mm    412х78х83
Weight, kg    0,9
SKU (Model #)    76548

Pulsar AXION 2 XG35 with laser rangefinder

• 640x480 pix. @ 12 µm (NETD <40 mK)
• 1100-yard rangefinder included
• Objective lens: F35/1.0
• Magnification: 2.5 - 20x (x8 zoom)
• Field of view (HxV), degrees / m@100m: 12.5x9.4 / 21.9x16.4
• Thermal Monocular with Laser Rangefinder (640x480 pix. @ 12 µm (NETD <40 mK))

Pulsar’s pocket-sized thermal monocular family - the Axions - have another member - the Axion 2 LRF XG35! With a powerful 640x480 microbolometer that detects heat signatures over 1900 yards away, this is an excellent device for scoping large areas and locating prey. With an included 1100-yard laser rangefinder, this device gives shooters an accurate approximation of their target’s distance. It then transmits these images and information to a pristine 1024x768 AMOLED display, giving the user clear, crisp image of their target.

With 2.5 - 20x magnification along with a built-in photo and video recording, Wi-Fi connectivity and a 16GB memory card, the Axion 2 LRF XG35 is a technological wonder. The Axion 2 is also supported by the Stream Vision 2 app, enabling shooters to record and preserve all their precious shooting memories.

Weighing a mere 0.6lbs, the Axion 2 LRF XG35 is made of a high-quality reinforced magnesium alloy that boasts IPX7 protection and operates in temperatures between -13F to 122F. Utilizing a Pulsar APS5 Li-ion battery, the Axion 2 LRF XG35 operates for up to 7 hours.

​
Enhanced Image Processing Algorithms

The Axion 2 thermal imaging devices use a new approach to image optimization depending on the purposes and conditions of observation and provide a high-quality rendering of both target objects and background. Three levels of signal amplification in combination with a connected smoothing filter and fine brightness and contrast adjustments give the hunter great opportunities for long-range detection of the animal under different weather and temperature conditions and determining its trophy qualities.

High-quality Reinforced Magnesium Alloy Housing

Axion is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat, or cold. At the same time, a metal housing effectively removes the heat from electronics, minimizes image noise, and increases the consistency of the device operation during long-term observation.

Highly-sensitive European-made Lynred Sensor

The Axion 2 thermal monoculars are equipped with European Lynred sensors with a resolution of 384x288 pixels (pixel size 17 µm) / 640x480 pixels (pixel size 12 µm), which qualitatively capture a useful signal under difficult observation conditions, such as rain, fog and high atmospheric humidity at the observation site.

​
Extended Battery Life. Up to 11 Hours on a Single Charge

A high-capacity APS5 rechargeable battery provides, depending on the model, up to 11 hours of continuous operation of the thermal imaging device on a single charge. The battery is removed from a battery housing and replaced with a new one in seconds. The battery is charged in a special charger or inside the device from a PC, household power system, or power bank via USB-C. The same sources are used for the external power supply of a thermal imaging device.

Improved Wi-Fi Connectivity with 2.4 / 5 GHz Waveband Support

In Axion 2 thermal imagers, the standard smartphone connection frequency range via a 2.4 GHz WiFi channel is complemented with an effective 5 GHz range. The 5 GHz connection offers better bandwidth, a faster data transfer rate, noise immunity, and improved connection stability, resulting in more productive and easier operation of the thermal imager with a smartphone.

Fast Aperture Lens

Germanium F35/1.0 lens features high infrared transmission in the LWIR range. Due to the high precision manufacturing of the optical elements of the lens, the image generated by the Axion 2 XQ thermal imaging device sensor is distinguished for its clarity and detailing.

​
Long-distance Laser Rangefinder

Understanding the target distance is an essential factor in making the right decisions. A built-in laser rangefinder with a range of up to 1 kilometer allows you to measure distances in single measurements and continuous scanning modes with an accuracy of ± 1 meter for quick and error-free assessment of the situation.

Built-in Photo and Video Recorder. Free 16 GB Cloud Space

The Axion 2 XQ has a built-in video recorder. The internal memory of the Axion 2 XQ can store hours of video and tens of thousands of photos. One touch of a button is enough to take a photo of an interesting scene or start recording a video. The footage is copied to a computer hard drive via a USB-C port. The Axion 2 XQ owner has a free 16 GB disk space for storing photos and videos captured with the device in the Pulsar cloud storage. Simply install the Stream Vision 2 mobile application, log in and connect the device with a smartphone via WiFi.

1300 m Detection Range

A powerful F35/1.0 objective lens combined with a 384x288 @ 17µm highly-sensitive thermal imaging sensor provides exceptional detection capabilities. A standard 1.8 m tall object can be detected up to 1300 m away in complete darkness.

​
Distant Operation and Firmware Update from Smartphone via Stream Vision 2 App

Built-in WiFi connects the Axion 2 XQ to Android and iOS smartphones via the Stream Vision 2 mobile application. This opens up a wide range of options including wireless device software updates, real-time image transmission from the device to the smartphone screen, publication on social media of photo and video content captured by the device or transfer to messengers, remote control of digital device functions and access to the latest news from Pulsar. Moreover, registered users receive 16 GB of cloud storage for photos and videos recorded with the device.

Variable Magnification from 2x to 8x

Digital zoom, up to 4x, provides improved focus and better overall object recognition at significant distances. The zoom changes either gradually in 2x step or continuously for a truly optimum, customized field of view for specific situation.

Field of View Over 10 Degrees

The Axion 2 XQ thermal imaging devices are suitable for viewing wide areas, observing in motion, or for moving objects - the linear field of view is 18.2 m at 100 m distance or 10.7° in angular values. The "Picture in Picture" function activates an additional window at the top of the display, in which the central area of the observed scene is shown magnified 2 or 4 times. This makes it possible to combine the information content of a wide field of view with detailed observation of the selected object.

A Selection of 8 Color Palettes

A choice of 8 color palettes lets the user observe their field of view more effectively, allowing them to optimize the unit for specific tasks as well as react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia, and Violet are most suitable for long observation at night.

Pocket-sized Dimensions and Lightweight

Axion 2 XQ has a space-saving and pocket-sized design and weighing 350 grams. The device is easy to grip and operate by right-handed and left-handed people due to the symmetrical design and in-line buttons arrangement on the upper panel.

High-contrast AMOLED Display

A high-contrast VGA-resolution AMOLED display has an improved color rendering, power-saving, and quick response, providing sharp and smooth images observing even under frosty conditions.

Fast Start-up

The Axion 2 XQ features a short turn-on time: the device is fully functional within 5 seconds after pressing the ON button. Quick start-up helps save battery power: when hunting, the Axion 2 XQ doesn't need to be kept ready at all times, simply turn it on when needed.

IPX7 Fully Waterproof

IPX7 is waterproof-rated for protection from heavy rainfall, snow, or other precipitation. The unit is designed to run flawlessly, even after submersion in up to 1 meter of water for up to 30 minutes.

Tech Specs
Sporting Optics Thermal
Detector Size    640 x 480 Sensor
Image Frequency    50 Hz
Optical Magnification    20 x
Max Digital Zoom    4 x
Video / Image    Onboard
Detection Range    1300 M (4265.09 Ft)
Lens Size    F35/1.0
Pixel Pitch    12 microns (0.012 MM)
Thermal Imagers/Hunting and Outdoor Thermal Imagers Template
Magnification    2.5 - 20x
Test Equipment General Attributes
Warranty    3 YEARS
Interfaces I/O    Wifi, USB-C
Storage    Internal Memory
IP Rating    IPX7
Product Weight    0.35 KILOS (0.772 LBS)
Product Height    152 MM (5.98 IN)
Product Length    74 MM (2.91 IN)
Product Width    75 MM (2.95 IN)
Shipping Weight    0.89 LBS
ECCN Number    ITAR
Battery Type    Li-ion
Power Supply Voltage    Battery Powered

In The Box
Axion 2 LRF Thermal Monocular
APS 5 Rechargeable Battery
(2) Battery-locking Covers
Power Adapter
USB Type-C Cable
Carrying Case
Hand Strap
Quick Reference User Manual
Lens Cleaning Cloth
Warranty Information
Tripod Adapter

Introducing the Pulsar Talion XQ35 Pro Thermal Rifle Hunting Scope. Replacing the previous Talion XQ38 model, the new XQ35 Pro offers an improved image quality, <25mk NETD rating for more detailed imaging and a wider field of view. The Pulsar Talion XQ35 Pro takes an already great scope and makes it even better!

The Pulsar Talion XQ35 Pro's 384x288 thermal resolution enables you to detect targets with utmost clarity, even in challenging environments and poor conditions. With a remarkable sub <25mk NETD rating sensor, you'll experience enhanced sensitivity, providing a significant advantage when spotting animals at a wide range of distances

Equipped with a 2.5x base magnification and wide FOV, the Talion XQ35 Pro lets you observe targets up close but the powerful 10x digital zoom allows you to hone in on your target at longer ranges ensuring you never miss a shot. Whether it's a distant coyote or an up close hog lurking in the brush, the XQ35 Pro provides a positive ID range at up to 250 yards, giving you the confidence to make accurate decisions in the heat of the hunt.

Not only does the Pulsar Talion XQ35 Pro deliver excellent performance, but it also includes a huge list of great features such as; internal audio and video recording, WiFi streaming with the Pulsar Stream Vision 2 app, picture in picture function, multiple reticles options and a wide variety of color pallets. With a recoil rating up to a 12 gauge shotgun or a .375 H&H and multiple rifle zeroing profiles, you can easily swap the Talion between different rifles. The Talion also features a fully removable and rechargeable Pulsar APS5-T battery pack that will allow you to stay in the field for hours on end.

If you're looking for an affordable thermal scope that still offers great image quality and all the features you want and need for your time in the field, look no further than the Pulsar Talion XQ35 Pro.

Features

• Long operation time on a single charge

Talion is powered with a Pulsar APS 5T interchangeable, rechargeable battery. A single charge guarantees up to 9 hours of battery life (Talion XQ series), which covers the time of active use of the scope for a hunt. The battery cover design helps to accurately determine the correct position and makes it possible to quickly replace a flat battery with a new one in complete darkness by touch alone.

• Multi-point prism mount for precise positioning on a rifle

A mounting prism with multiple screw points to ensure flexibility and convenience when installing a Talion riflescope on various types of rifles. During installation the user can shift the scope along the rifle to the most comfortable viewing position.

• All control elements in direct access

All Talion riflescope controls are placed on the top panel of the eyepiece to simplify access and for the convenience of both right- and left-handed users.

• Rapid battery extraction mechanism

Unique battery cover design with rapid extraction lock ensures fast and flawless battery replacement. Releasing the lock opens and raises the battery cover at the top of the riflescope’s housing for quick access to rechargeable battery.

• Focus adjustment with tactile marker set for night-time shot

The precise focusing adjustment has an integrated fin lever that is set to match the protruding ridge on the housing of Talion riflescope when focusing reaches 70 m (76 yd) mark, the night-time shooting distance. This enables quick and correct focusing, even without looking at the riflescope.

More sensitive than ever

• User mode

Use the brightness and contrast adjustments to maximise the detail and informative value of the image in specific observation conditions. The User Mode function saves selected brightness and contrast settings in the device's memory providing optimal image quality for the next use of the thermal imager immediately, with no additional adjustments needed.

• 3 sensitivity amplification levels

Selection of the signal amplification level combined with new filtration algorithms with fine brightness and contrast adjustments offers the hunter great opportunities for long-range detection of game under diverse weather and temperature conditions. The amplification setting helps to define an animal’s trophy features and ensures clear rendering of objects and background in the field of view.

• Lightweight and rugged magnesium alloy housing

The Talion’s housing is made of magnesium alloy to ensure great structural strength and retain a light weight. The robust and lightweight metal housing serves also as a heat sink extracting the warmth generated by inner electronics thus making thermal imaging device more sensitive.

• Photo and video recording

Keep the best moments of observation and share them with your friends and hunting colleagues. One touch of a button is enough to capture an interesting moment or start recording video. 16 GB of internal memory enables recording many hours of video and tens of thousands of photos.

• Wi-Fi integration with iOS and Android devices. Stream Vision 2 application

The built-in Wi-Fi module will connect the device with smartphones based on Android and iOS via the Stream Vision 2 mobile application. This combination provides a great opportunity, such as wireless updating of the device software, transmission of images to a mobile device screen in real time, remote control of digital functions and many others. Users registered in the application are provided with cloud storage space for photos and videos taken with a digital or thermal imaging device.

• Waterproof IPX7 housing

With an IPX7 waterproof rating, Talion riflescopes work in conditions of high humidity and heavy rain and can withstand half an hour immersion under water to a depth of 1 meter.

High calibre recoil resistance: 12 gauge, 9.3x64, .375H&H

Talion thermal riflescopes are high impact resistant and can be used with rifled hunting weapons with calibres of 9.3x64, .30-06, .300, .375H&H, etc., as well as with smooth-bore and pneumatic weapons.

• 5 shooting profiles / 50 zeroing distances

Zeroing settings are saved in a shooting profile. Talion memory contains up to five shooting profiles for several types of weapons or cartridges. Each profile can hold up to ten zeroing distances.

• A selection of 10 reticle shapes in 9 colour modes

A reticle is electronically displayed in the same plane as the target. The Talion memory contains ten reticle configurations and functions (direct shot type, ballistic, scalable and regular), all available in nine colour options.

• Precision aiming in the “Picture-in-picture” mode

The “Picture-in-picture” function enables the shooter to display a high-precision zeroing frame. Taking only 10% of the total display area, the frame shows a magnified image of the target and reticle and allows the user to closely see the image in the aiming area and have visual control of the entire field of view at the same time.

• Variable colour palettes

A choice of 8 colour palettes lets the user observe their field of view more effectively, allowing them to optimise the unit for specific tasks and react to changing observation conditions. White Hot, Black Hot and Red Hot are optimal for object detection, and Rainbow and Ultramarine help increase chances for recognition & identification. Red Monochrome, Sepia and Violet are best suited to long-range observation at night.

Mounts
Talion riflescopes come in 4 versions:

• Without the mount
• Equipped with the Weaver U Mount
• Equipped with the Weaver USQD Mount
• Equipped with the Weaver LQD Mount

Specifications:

Main

• Sensor: 384x288 @ 12 µm (NETD <25 mK)
• Objective lens: F35 / 1.0
• Magnification: 2.5 – 10x (x8 zoom)
• Field of view (HxV): 10.7х8 / 18.2x13.7
• Detection range: 1350m

Sensor

• Type: uncooled
• Resolution: 384x288 pixels
• Pixel pitch: 17µm
• NETD: < 25mK
• Frame rate: 50Hz

Optics

• Objective lens: F35 / 1.0
• Magnification: 2.5 – 10
• Field of view (HxV), degrees / m @ 100 m: 10.7х8 / 18.2x13.7
• Eye relief: 50mm

Display

• Type: AMOLED
• Resolution, pixels 1024х768

Reticle

• Click value, H/V, mm at 100 m: 18 / 18 (on minimum magnification)
• Click range, H/V, mm at 100 m: 3600 / 3600
• Number of preloaded reticles: 10

Video Recorder

• Video / photo resolution: 1024x768 pixels
• Video / photo format: .mp4 / .jpg
• Built-in memory: 16GB

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz

Environmental Characteristics

• Degree of protection: IPX7 IP code (IEC60529)
• Operating temperature range: -25 – +50 °С

Connections and Compatibilities

• Max. recoil power on rifled weapon (Eo): 6000Joules
• Shock resistance on the smooth-bore rifles, caliber: 12
• Compatible mounts: Weaver U Mount, Weaver USQD Mount, Weaver LQD Mount
• Supported Application: Stream Vision 2

Power Supply

• Output voltage: 3.0 – 4.2V
• Battery type: APS 5T
• Capacity: 4900 mAh
• Operating time on battery pack (at t=22°C), h *: 9
• External power supply: 5 V, 9 V (USB Type-C Power Delivery)

Weight & Size

• Body material: Magnesium alloy
• Dimensions: 330x57x67mm
• Weight: 0.7kg (without APS 5T battery)

Trade Data

• SKU (Model #): 76566

The Telos XQ35 stands as a powerful optic. With a <25mK NETD sensor and enhanced image processing algorithms, this powerful thermal monocular gives users highly refined details, even in the toughest conditions.

For the first time in a Pulsar product, the Telos XQ35’s adjustment rings allow users to gradually zoom in and focus in one fluid motion. This fine camera-like digital control system allows smooth magnification adjustments and pristine quality even at high magnifications. Its built-in laser rangefinder has a range of 1000 Metres – helping users survey areas and target objects within a practical accuracy of 1 Metre.

Further enhancing its range viewing abilities, the Telos XQ35 has a detection range of more than 1,300 Metres, capable of detecting human-sized heat sources in the harshest weather.

The Telos XQ35 is also built to last. From arctic conditions to wetland swamps, this unit continuously provides reliable heat detection. With a temperature resistance of -25 to +40°C the Telos is built to withstand different environments, hot or cold.

Outfitted with a brand new LPS 7i quick-charge Lithium-ion battery, the Telos has more than 8.5 hours of battery life and can be charged with any USB-C compatible charging device, including common cellphone chargers. The LPS 7i also supports wireless charging.

Designed for longevity and crafted with care and precision, Pulsar’s Telos is the only thermal monocular you will ever need.

Telos is the new concept of upgradeable thermal imaging monoculars. It is the first line of thermal devices on the market to offer the option of technical hardware upgrade. The components of the Telos can be replaced with new ones featuring better characteristics. The user doesn’t need to acquire a new device every time a newer technology is being introduced. Telos is designed to be time resistant and future-proof. And to constantly adapt to the ever-changing needs of a hunter. With the new Pulsar upgradeability concept your Telos will become a renewable device. Or, if you wish, a device for life.

Possible upgrade types:

• Addition of the laser rangefinder for the non-LRF models
• Sensor upgrade
• Objective lens upgrade

Features

• Highly sensitive thermal sensor
• Advanced Pulsar Image Boost technology
• Objective ring zoom control
• Built for the toughest conditions
• Replaceable battery pack with direct plug & wireless fast charge options
• Ergonomic, nonslip rubber-coated housing
• Adaptable for left- and right-handed use
• Ergonomic and functional carrying case
• User Mode saves selected brightness and contrast settings
• 1000 m range for LRF (Laser Range Finder)
• 1300 m Thermal detection range
• Stream Vision 2. Wi-Fi integration with iOS and Android devices
• Fast aperture F35/1.0 germanium lens
• High-contrast AMOLED display
• IPX7 submersion waterproof-rated
• Built-in video recorder with 64GB internal memory
• A selection of 8 colour palettes

Main

• Sensor: 384x288 pix. @ 17 µm (NETD <25 mK)
• Objective lens: F35 / 1.0
• Magnification: 3 – 12x (x4 zoom)
• Field of view (HxV), degrees / m @100m: 10.7x8° / 18.7x14°
• Eye relief: 14 mm
• Detection range: 1300 m
• Operating time on battery pack (at t=22°C): 8.5 Hours

Sensor

• Type: uncooled
• Resolution: 384x288 p
• Pixel pitch: 17 µm
• NETD: <25 mK

   Display

• Type: AMOLED HD
• Resolution: 1024x768 p
• Frame rate: 50Hz
• Video Recorder
• Video / photo resolution: 1024x768p
• Video / photo format: .mp4 / .jpg
• Built-in memory,: 64 gb

Laser Rangefinder

• Safety class for laser equipment according to IEC 60825-1:2014: 1
• Wavelength: 905 nm
• Max. measuring range: 1000 m
• Measurement accuracy: ± 1 m

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 Ghz

   Environmental Characteristics

• Degree of protection, IP code (IEC60529): IP?7 (waterproof)
• Operating temperature range: -25 – +40 °?

Connections and Compatibilities

• Mount Type: 1/4"
• Supported Application: Stream Vision 2

Power Supply

• Output voltage: 3.0 – 4.2 V
• Battery type: LPS 7i Li-Ion Battery Pack
• Capacity: 6400 mAh
• Operating time on battery pack (at t=22°C): 8.5 Hours
• External power supply: 5V & 9V (USB Type-C Power Delivery)

Weight & Size

• Body material: Rubber armoured reinforced plastic
• Dimensions: 224 x 66 x 87 mm
• Weight: 630 grams

The Axion 2 Series LRF is a great addition to your hunt. Combining both Laser Rangefinding & Thermal imaging into one unit will save you time & keep things all in one place while out hunting.

The Pulsar Axion 2 replaces the previous model, the Pulsar Axion. It has the following new benefits:

• Wider field-of-view
• Longer lasting battery life
• Stream Vision 2 compatible
• New dual-band WiFi module

Difference in models

• The XQ35 is the base model of the Axion 2 LRF Series
• The XQ35 Pro has a sub 25 milliKelvins Sensor which allows it to be more sensitive to temperature differences
• The XG35 is the top of the range for the Axion 2 LRF series (benefits are compared below)

1. Better Sensor: 640x480 (compared to 384x288 on XQ35)
2. Better Display: 1024x768 (compared to 640x400 on XQ35)
3. Further Detection range: 1750 metres (compared to 1300 on XQ35)
4. Higher Zoom: 2.5 - 20 (8x zoom) (compared to 2 - 8 (4x zoom) on XQ35)

Please Note: As the XG35 is more powerful it does have a shorter run time of 7 hours

Axion 2 LRF thermal imaging monoculars are designed for use both at night-time and during the day and provide exceptional image quality even in adverse weather conditions (fog, smog, rain) and beyond obstacles like branches, tall grass, dense foliage, etc. known to hinder target detection.

Unlike night-vision devices based on electron-optical converters, thermal imaging devices do not need an external light source and are resistant to bright light.

Axion 2 LRF thermal imagers are designed for various applications including hunting, observation, security, terrain orientation, search and rescue operations, etc.

Axion 2 LRF thermal imagers are equipped with a built-in laser rangefinder with a range of up to 1000 m and a measurement accuracy of ± 1 m.

• Compact and lightweight
• Functional and ergonomic design
• 8-colour display palette
• 3 calibration modes: Manual, Semi-Automatic, Automatic
• Detection range up to 1300 m/1422 yds
• Smooth digital zoom 2-8x
• Three levels of sensitivity enhancement: Normal, High, Ultra
• Integrated laser rangefinder
• Display-Off function
• Defective pixel repair
• Updatable firmware
• Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
• Fully waterproof (IPX7 rated)
• Tripod mount

Video/Audio Recording

• Built-in video and sound recorder
• Integration with iOS and Android devices
• Wi-Fi remote control and viewing using a smartphone
• Storing photos and videos in Cloud when using the Stream Vision 2 App

Battery Pack

• Quick Change Li-Ion Battery Pack APS 5
• Charging from USB Power Bank
• Quick-Charge power delivery​

Main

• Sensor: 384x288 pix. @ 17 µm (NETD <25 mK)
• Objective lens: F35 / 1.0
• Magnification: 2 – 8x (x4 zoom)
• Field of view (HxV) @ 100 m: 10.7х8° / 18.2x13.7°
• Detection range: 1300 m
• Display Type: AMOLED
• Display Resolution: 640x400 Pixels

Sensor

• Sensor Type: uncooled
• Resolution: 384x288 Pixels
• Pixel pitch: 17µm
• NETD: <25 mk
• Frame rate: 50 Hz

Optics

• Objective lens: F35 / 1.0
• Magnification: 2 – 8x (x4 zoom)
• Field of view (HxV) @ 100 m: 10.7х8° / 18.2x13.7°
• Eye relief: 14 mm

Range Performance

• Detection range: 1300 m

Laser Rangefinder

• Wavelength: 905 nm
• Max. measuring range: 1000 m
• Measurement accuracy: ± 1 M

Video Recorder

• Video/photo resolution: 528x400 Pixel
• Video/photo format: .mp4 / .jpg
• Built-in memory: 16GB

Wi-Fi

• Wireless Protocol: Wi-Fi
• Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
• Frequency: 2.4 / 5 GHz

Environmental Characteristics

• Degree of protection, IP code (IEC60529): IPХ7 (waterproof)
• Operating temperature range: -25 to +40°С

Connections and Compatibilities

• Mount type:1/4"
• Supported Application: Stream Vision 2

Power Supply

• Output voltage:   3.0 – 4.2V
• Battery type: APS 5 Li-ion Battery Pack
• Capacity: 4900mAh
• Operating time on battery pack (at t=22°C): up to 11 Hours
• External power supply: 5V, 9V (USB Type-C Power Delivery)

Weight & Size

• Body material: Magnesium alloy
• Dimensions: 152 x 74 x 75mm
• Weight: 0.47 Kgs(with the APS5 battery)

In The Box

• Axion 2 LRF Thermal Monocular
• APS 5 Rechargeable Battery
• (2) Battery-locking Covers
• Power Adapter
• USB Type-C Cable
•  Carrying Case
• Hand Strap
• Quick Reference User Manual
• Lens Cleaning Cloth
• Warranty Information
•  Tripod Adapter

The Warranty period on new thermal optics:

• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period than what is specified for the units above. The warranty does not cover misuse or accidental damage caused by the operator.

The Pulsar Axion 2 replaces the previous model, the Pulsar Axion. It has the following new benefits:
• Wider field-of-view
• Longer lasting battery life
• Stream Vision 2 compatible
• New dual-band WiFi module

Difference in models

XQ35 is the base model of the Axion 2 (non-LRF)Series - Pulsar Axion 2 XQ35 Handheld Monocular Thermal

XQ35 Pro has a sub 25 milliKelvins Sensor which allows it to be more sensitive to temperature differences

XG35 is the top of the range for the Axion 2 (non-LRF) series (benefits are compared below) - Pulsar Axion 2 XG35 Handheld Monocular Thermal

1.) Better Sensor: 640x480
2.) Better Display: 1024x768p + AMOLED HD
2.) Further Detection range: 1750 metres
3.) Higher Zoom: 2.5 - 20(8x zoom)
Please Note: As the XG35 is more powerful it does have a shorter run time of 7 hours

Axion 2 thermal imaging monoculars are designed for use both at night-time and during the day and provide exceptional image quality even in adverse weather conditions (fog, smog, rain) and beyond obstacles like branches, tall grass, dense foliage, etc. known to hinder target detection.

Unlike night-vision devices based on electron-optical converters, thermal imaging devices do not need an external light source and are resistant to bright light.

Axion 2 thermal imagers are designed for various applications including hunting, observation, security, terrain orientation, search and rescue operations, etc.

• Compact and lightweight
• Functional and ergonomic design
• 8-colour display palette
• 3 calibration modes: Manual, Semi-Automatic, Automatic
• Detection range up to 1300 m/1422 yds
• Smooth digital zoom 2-8x
• Three levels of sensitivity enhancement: Normal, High, Ultra
• Display-Off function
• Defective pixel repair
• Updatable firmware
• Wide operating temperature range (-25°С to +40°С / -13°F to +104°F)
• Fully waterproof (IPX7 rated)
• Tripod mount

Main
• Sensor: 384x288 pix. @ 17 µm (NETD <25 mK)
• Objective lens: F35 / 1.0
• Magnification: 2 – 8x (x4 zoom)
• Field of view (HxV) @ 100 m: 10.7х8° / 18.2x13.7°
• Detection range: 1300 m
• Display Type: AMOLED
• Display Resolution: 640x400 Pixels

Weight & Size
• Body material: Magnesium alloy
• Dimensions: 152 x 74 x 75mm
• Weight: 0.47 Kgs(with the APS5 battery)

In The Box
• Axion 2 Thermal Monocular
• APS 5 Rechargeable Battery
• (2) Battery-locking Covers
• Power Adapter
• USB Type-C Cable
• Carrying Case
• Hand Strap
• Quick Reference User Manual
• Lens Cleaning Cloth
• Warranty Information
• Tripod Adapter

The Warranty period on new thermal optics:
• Pulsar: 3 Year manufacturers warranty
• Guide: 1 Year + Register online and get an extra year: https://www.guideir.com/service/free-extended-warranty

Please note: Manufacturers warranty period above covers the unit itself and does not cover commercial use. Thermal accessories will have a lesser cover period than what is specified for the units above. The warranty does not cover misuse or accidental damage caused by the operator.
