Garmin Alpha 200i & TT15X Collar Package

The Alpha 200i dog tracking and training system lets you monitor up to 20 dogs from up to 9 miles (depending on dog device) on a 3.5" display with a 2.5-second update rate. Easily control training functions by using the button-operated, dog-focused design.

You’ll also have access to premium Garmin navigation features, such as preloaded TopoActive maps, BirdsEye Satellite Imagery with direct-to-device downloads and built-in three-axis compass and barometric altimeter. Now, inReach® technology adds twoway messaging and interactive SOS alerts for peace of mind while you’re in the field.

LARGE 3.5"DISPLAY WITH SIX-BUTTON DESIGN
Features sunlight-readable 3.5" capacitive touchscreen display and a button-operated, dog-focused design for
quick, minor adjustments

TRACK YOUR PACK Monitor up to 20 dogs from up to 9 miles (depending on dog device) with a 2.5-second updaterate

DOG LIST AND GROUP MANAGEMENT Dog list and group management lets you keep inactive dogs in the system for easier setup

INREACH® TECHNOLOGY Interactive SOS alerts and two-way messaging via the 100% global Iridium® satellite network (satellite subscription
required)

MULTI-GNSS SUPPORT Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone

TOPOACTIVE MAPS Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits,
parks, coastlines, rivers, lakes and geographical points

BIRDSEYE SATELLITE IMAGERY Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads,
clearings and more

NAVIGATION SENSORS A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure,
and the built-in tilt-compensated three-axis electronic compass keeps your bearing — whether you’re moving or not

TRAINING OPTIONS (TT™ 15/ TT 15 MINIONLY) When paired with TT™ 15 tracking and training collars, you will have access to 18 levels of continuous and
momentary stimulation, plus vibration and adjustable tones

FEDERAL PUBLIC LAND BOUNDARIES
Optional display of federal public land boundaries on topographical maps shows Bureau of Land Management,
National Parks and Wilderness so you know that you’re venturing where you’re supposed to be

HUNT TIMER FUNCTION Use the convenient timer mode during hunting competitions or field trials; get quick access to the timer with the new
user-configurable buttons

PRO VIEW COMPASS The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away
your dogs are, plus you will see when a dog is “Treed” or “On Point”

GARMIN EXPLORE™ Compatible with Garmin Explore website and app to help you manage tracks, routes and waypoints and review statistics from the field

ADDITIONAL MAPPING The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand. 24K
and Garmin HuntView™ Plus maps (sold separately)

GARMIN ECOSYSTEM Track your pack from the road, your wrist and other ways, thanks to wireless connectivity with compatible Garmin
devices, such as the Garmin DriveTrack™ 71 GPS navigator, fēnix® 6 GPS watches andmore

BACKWARD COMPATIBLE Backward compatible so you can keep your existing collars and other Alpha compatible devices; transfer location
data between compatible Garmin devices

LONG-LASTING BATTERY Replaceable battery lasts up to 20 hours, or up to 15 hours with inReach technology enabled

PRODUCT NUMBER: 010-02230-53



The TT 15X dog tracking and training device has a top-mounted, high-sensitivity GPS and GLONASS receiver, so you can track your dog from up to 14.5 km away. Rugged and water-resistant to 10 metres (1 ATM), it’s tough enough to run wherever your dog runs. Plus, with up to 80 hours of battery life and sleep mode to remotely put the device to sleep, you can focus on the hunt instead of the next charge.

TT 15X features 18 levels of continuous and momentary stimulation plus audible tone and vibration when used with your compatible tracking and training handheld.

LED beacon lights, activated from your compatible handheld, help keep track of your dog in the field. Visible up to 90 metres away, the lights work in low-light conditions and at night.

TT 15X ships with a 1″ red collar strap.

 Specifications:
• Unit dimensions (WxHxD): 3.50″ x 1.75″ x 1.85″ (8.90 x 4.40 x 4.70 cm)
• Weight: 7.30 oz (207 g) for transmitter and antenna (without collar); 10 oz (284 g) total weight (with collar)
• Battery type: Rechargeable lithium-ion pack; user-replaceable
• Battery life: Up to 80 hours
• Range: 14,5 kilometres
• Interface: USB
• Water rating: 1 ATM (10 metres)
• Neck size: Minimum of 9.5″ (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: Top, black
• Stimulation/Vibration/Tone: Yes
• LED beacon lights: Yes
• Sleep mode: Yes
• Rescue mode: Yes
• Frequency mode: MURS
• Replaceable collar straps: Yes
• Collar compatibility: 1″ (2.54 cm)
• Software updates: Via Garmin Express™ software, available for both Mac® and Windows®

Contents:
• TT 15X dog device with rechargeable lithium-ion battery pack
• 1″ red collar strap
• 18.5″ standard antenna
• 22.5″ extended-range antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Contact point set with spanner
• Documentation

Strong connection, strong bond.

Track and train your dogs with the Alpha 200i system, featuring inReach® Iridium satellite technology, a sunlight-readable 3.5 inch capacitive touchscreen and user-friendly, six-button design.

Take dog tracking and training to the next level.

TRACK YOUR PACK: Monitor up to 20 dogs from up to 14.5 kilometres (depending on dog device) with a 2.5-second update rate.

DOG LIST/GROUP MANAGEMENT: Keep inactive dogs in your dog list, and manage active groups so you don't have to add and remove dogs for every hunt.

SIX-BUTTON DESIGN: Use dedicated buttons for fast training cues and minor adjustments in the field.

18 LEVELS OF STIMULATION: Momentary and continuous stimulation options let you customise training for each dog.

TONE/VIBRATION: Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs.

PRO VIEW COMPASS: The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away your dogs are, plus you will see when a dog is Treed or OnPoint.

Navigate your surroundings.

MULTI-GNSS SUPPORT: Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone.

TOPOACTIVE MAPS: Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

BIRDSEYE SATELLITE IMAGERY: Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads, clearings and more.

NAVIGATION SENSORS: A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure, and the built-in tilt-compensated three-axis electronic compass keeps your bearing — whether you're moving or not.

SEE IT ALL: The sunlight-readable 3.5 inch capacitive touchscreen display makes it easy to see and interact with your maps, dog data and more.

STAY ON THE MOVE: Replaceable battery lasts up to 20 hours, or up to 15 hours with inReach technology enabled.

ADDITIONAL MAPPING: The microSD™ card slot allows you to load more mapping options, such as TOPO and HuntView Plus maps (sold separately).

Stay in touch using inReach technology.

TWO-WAY MESSAGING: Exchange text messages with loved ones, post to social media, or communicate inReach to inReach in the field (satellite subscription required).

INTERACTIVE SOS: In case of emergency, trigger an interactive SOS message to GEOS, a professional 24/7 global monitoring and response centre (satellite subscription required).

LOCATION SHARING: Track your location, and share it with those at home or out in the field so they can see your progress or ping your device for your GPS location and more (satellite subscription required).

100% GLOBAL IRIDIUM® SATELLITE NETWORK: Instead of relying on mobile coverage, now your messages, SOS alerts and tracking are transferred via the global Iridium satellite network (satellite subscription required).

Specifications:
General
• PHYSICAL DIMENSIONS: 6.8 x 16.2 x 3.4 cm *dimensions do not include antenna
• TOUCHSCREEN: Yes
• DISPLAY SIZE: 4.7 W x 7.7 H cm; 3.5 inch diag (88.9 mm)
• DISPLAY RESOLUTION: 282 x 470 pixels
• DISPLAY TYPE: Transflective, colour TFT touchscreen
• WEIGHT: 280 g with standard antenna and battery
• BATTERY TYPE: Rechargeable lithium-ion (included)
• BATTERY LIFE: Up to 20 hours; up to 15 hours with inReach® technology enabled
• WATER RATING: IPX7
• HIGH-SENSITIVITY RECEIVER: Yes
• INTERFACE: High-speed USB
• MEMORY/HISTORY: 16 GB

Maps & Memory
• PRELOADED MAPS: Yes (TopoActive)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• BIRDSEYE: Yes, direct to device (no annual subscription required)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• TRACKS: Up to 20 dogs (TT 15/TT 15 mini and T5/T 5 mini) and buddies (Alpha 100 and Alpha 200i) simultaneously
• TRACK LOG: 20,000 points, 250 saved gpx tracks, 300 saved fit activities
• ROUTES: 250
• STORED CONTACTS: 250 dogs
• GROUP MANAGEMENT: Yes

Sensors
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Safety and Tracking Features
• LIVETRACK: yes (with Garmin Explore™)

Outdoor Recreation
• SUN AND MOON INFORMATION: Yes
• CUSTOM MAPS COMPATIBLE: Yes

inReach® Features
• INTERACTIVE SOS: Yes
• SEND AND RECEIVE TEXT MESSAGES TO SMS AND EMAIL: Yes
• EXCHANGE LOCATIONS WITH OTHER INREACH DEVICE: Yes
• VIRTUAL KEYBOARD FOR CUSTOM MESSAGING: Yes
• SEND WAYPOINTS TO MAPSHARE DURING TRIP: Yes
• SEND ROUTE SELECTION TO MAPSHARE DURING TRIP: Yes

Two-way Radio Features
• FREQUENCY BAND: VHF
• RANGE: TT 15/T 5, 14.5 kilometres; TT 15 mini/T 5 mini, 6.5 kilometres

Outdoor Applications
• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections
• WIRELESS CONNECTIVITY: Yes (Wi-Fi®, Bluetooth® and ANT+®)

Garmin TT 15 Mini GPS Dog Collar

A top-mounted, high-sensitivity GPS/GLONASS receiver, TT 15 mini dog device uses 18 levels of continuous and momentary stimulation, plus audible tone and vibration when used with a compatible dog device.

Rugged and water-resistant to 10 meters, this tracking and training dog device with collar is tough enough to run wherever your dog runs, up to 4 miles away. The stimulation features let you train each dog separately — traditional stimulation allows you to make quick changes (low, medium or high) within a predetermined stimulation level (1-6), whereas linear stimulation allows progressively more stimulation from levels 1 to 18. You can remotely operate the LED beacon lights, built in to the dog device, to help locate your dog in low-light conditions.

TT 15 mini ships with a 3/4-inch red collar strap. Replacement straps are available in multiple colors (sold separately). TT 15 mini is compatible with track only handhelds but the training tools will not function. The T5 mini is recommended for track only handhelds.

Garmin Alpha 200 & TT15X Collar Package

STRONG CONNECTION. STRONG BOND. Track and train your dogs with the Alpha 200, Handheld Only system, a sunlight-readable 3.50″ capacitive touchscreen and user-friendly, six-button design.

Key Features:
• This handheld is designed to help make tracking and training simple, accessible and fast.
• Track and train your pack while they’re out in the field.
• Keep inactive dogs in the system for easier setup and management.
• Navigate every hunt with the best in Garmin mapping and sensors.
• User-replaceable battery lasts up to 20 hours.

TRACK YOUR PACK. Monitor up to 20 dogs from up to 14.50 kilometres (depending on dog device) with a 2.50-second update rate.

DOG LIST/GROUP MANAGEMENT. Keep inactive dogs in your dog list, and manage active groups so you don’t have to add and remove dogs for every hunt.

PUBLIC LAND BOUNDARIES. Optional display of public land boundaries on topographical maps helps you know that you’re venturing where you’re supposed to be.

HUNT METRICS. See each dog’s daily hunting patterns, distance and speed so you can monitor performance and help prevent overheating. Pair with TT™ 15 tracking and training collars.

SIX-BUTTON DESIGN. Use dedicated buttons for fast training cues and minor adjustments in the field.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog.

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs.

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

PRO VIEW COMPASS. The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away your dogs are, plus you will see when a dog is “Treed” or “OnPoint.”

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone.

TOPOACTIVE MAPS. Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

BIRDSEYE DIRECT. Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads, clearings and more.

NAVIGATION SENSORS. A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure, and the built-in tilt-compensated 3-axis electronic compass keeps your bearing - whether you’re moving or not.

SEE IT ALL. The sunlight-readable 3.50″ capacitive touchscreen display makes it easy to see and interact with your maps, dog data and more — even while wearing gloves.

STAY ON THE MOVE. Replaceable battery lasts up to 20 hours, giving you plenty of hunt time with your dogs in the field.

ADDITIONAL MAPPING. The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand Light and HuntView maps (each sold separately).

Specifications:
• PHYSICAL DIMENSIONS: 7.70 x 6.40 x 1.30″ (6.80 x 16.20 x 3.40 cm) *dimensions do not include antenna
• TOUCHSCREEN: Yes
• DISPLAY SIZE: 1.80″ W x 3.0″ H (4.70 x 7.70 cm); 3.50″ diag (88.90 mm)
• DISPLAY RESOLUTION: 282 x 470 pixels
• DISPLAY TYPE: Transflective, colour TFT touchscreen
• WEIGHT: 9.90 oz (280 g) with standard antenna and battery
• BATTERY TYPE: Rechargeable lithium-ion (included)
• BATTERY LIFE: Up to 20 hours
• WATER RATING: IPX7
• HIGH-SENSITIVITY RECEIVER: Yes
• INTERFACE: High-speed USB
• MEMORY/HISTORY: 16 GB
• PRODUCT NUMBER: 010-02616-53

Maps & Memory
• PRELOADED MAPS: Yes (TopoActive)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• BIRDSEYE: Yes, direct to device (no annual subscription required)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• TRACKS: Up to 20 dogs (TT 15/TT 15 mini and T5/T5 mini) and buddies (Alpha 100 and Alpha 200) simultaneously
• TRACK LOG: 20,000 points, 200 saved gpx tracks, 300 saved fit activities
• ROUTES: 250
• STORED CONTACTS: 250 dogs
• GROUP MANAGEMENT: Yes

Sensors
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Outdoor Recreation
• SUN AND MOON INFORMATION: Yes
• CUSTOM MAPS COMPATIBLE: Yes

Two-way Radio Features
• FREQUENCY BAND: MURS
• RANGE: TT 15/T5, 14.50 kilometres; TT 15 mini/T mini, 14.50 kilometres

Outdoor Applications
• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections
• WIRELESS CONNECTIVITY: Yes (Wi-Fi®, Bluetooth® and ANT+®)



The TT 15X dog tracking and training device has a top-mounted, high-sensitivity GPS and GLONASS receiver, so you can track your dog from up to 14.5 km away. Rugged and water-resistant to 10 metres (1 ATM), it’s tough enough to run wherever your dog runs. Plus, with up to 80 hours of battery life and sleep mode to remotely put the device to sleep, you can focus on the hunt instead of the next charge.

TT 15X features 18 levels of continuous and momentary stimulation plus audible tone and vibration when used with your compatible tracking and training handheld.

LED beacon lights, activated from your compatible handheld, help keep track of your dog in the field. Visible up to 90 metres away, the lights work in low-light conditions and at night.

TT 15X ships with a 1″ red collar strap.

 Specifications:
• Unit dimensions (WxHxD): 3.50″ x 1.75″ x 1.85″ (8.90 x 4.40 x 4.70 cm)
• Weight: 7.30 oz (207 g) for transmitter and antenna (without collar); 10 oz (284 g) total weight (with collar)
• Battery type: Rechargeable lithium-ion pack; user-replaceable
• Battery life: Up to 80 hours
• Range: 14,5 kilometres
• Interface: USB
• Water rating: 1 ATM (10 metres)
• Neck size: Minimum of 9.5″ (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: Top, black
• Stimulation/Vibration/Tone: Yes
• LED beacon lights: Yes
• Sleep mode: Yes
• Rescue mode: Yes
• Frequency mode: MURS
• Replaceable collar straps: Yes
• Collar compatibility: 1″ (2.54 cm)
• Software updates: Via Garmin Express™ software, available for both Mac® and Windows®

Contents:
• TT 15X dog device with rechargeable lithium-ion battery pack
• 1″ red collar strap
• 18.5″ standard antenna
• 22.5″ extended-range antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Contact point set with spanner
• Documentation

Garmin Alpha 200i & T5X Collar Package

The Alpha 200i dog tracking and training system lets you monitor up to 20 dogs from up to 9 miles (depending on dog device) on a 3.5" display with a 2.5-second update rate. Easily control training functions by using the button-operated, dog-focused design.

You’ll also have access to premium Garmin navigation features, such as preloaded TopoActive maps, BirdsEye Satellite Imagery with direct-to-device downloads and built-in three-axis compass and barometric altimeter. Now, inReach® technology adds twoway messaging and interactive SOS alerts for peace of mind while you’re in the field.

LARGE 3.5"DISPLAY WITH SIX-BUTTON DESIGN
Features sunlight-readable 3.5" capacitive touchscreen display and a button-operated, dog-focused design for
quick, minor adjustments

TRACK YOUR PACK Monitor up to 20 dogs from up to 9 miles (depending on dog device) with a 2.5-second updaterate

DOG LIST AND GROUP MANAGEMENT Dog list and group management lets you keep inactive dogs in the system for easier setup

INREACH® TECHNOLOGY Interactive SOS alerts and two-way messaging via the 100% global Iridium® satellite network (satellite subscription
required)

MULTI-GNSS SUPPORT Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone

TOPOACTIVE MAPS Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits,
parks, coastlines, rivers, lakes and geographical points

BIRDSEYE SATELLITE IMAGERY Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads,
clearings and more

NAVIGATION SENSORS A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure,
and the built-in tilt-compensated three-axis electronic compass keeps your bearing — whether you’re moving or not

TRAINING OPTIONS (TT™ 15/ TT 15 MINIONLY) When paired with TT™ 15 tracking and training collars, you will have access to 18 levels of continuous and
momentary stimulation, plus vibration and adjustable tones

FEDERAL PUBLIC LAND BOUNDARIES
Optional display of federal public land boundaries on topographical maps shows Bureau of Land Management,
National Parks and Wilderness so you know that you’re venturing where you’re supposed to be

HUNT TIMER FUNCTION Use the convenient timer mode during hunting competitions or field trials; get quick access to the timer with the new
user-configurable buttons

PRO VIEW COMPASS The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away
your dogs are, plus you will see when a dog is “Treed” or “On Point”

GARMIN EXPLORE™ Compatible with Garmin Explore website and app to help you manage tracks, routes and waypoints and review statistics from the field

ADDITIONAL MAPPING The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand. 24K
and Garmin HuntView™ Plus maps (sold separately)

GARMIN ECOSYSTEM Track your pack from the road, your wrist and other ways, thanks to wireless connectivity with compatible Garmin
devices, such as the Garmin DriveTrack™ 71 GPS navigator, fēnix® 6 GPS watches andmore

BACKWARD COMPATIBLE Backward compatible so you can keep your existing collars and other Alpha compatible devices; transfer location
data between compatible Garmin devices

LONG-LASTING BATTERY Replaceable battery lasts up to 20 hours, or up to 15 hours with inReach technology enabled

PRODUCT NUMBER: 010-02230-53

The K/T 5X dog device has a top-mounted, high-sensitivity GPS and GLONASS receiver, so you can track your dog from up to 14.5 kilometres away. It features a rugged design — water-resistant to 10 metres (1 ATM) — so it’s tough enough to run wherever your dog runs. Plus, with up to 80 hours of battery life and sleep mode to remotely put the device to sleep, you can focus on the hunt instead of the next charge.

LED beacon lights, activated from your compatible handheld, help keep track of your dog in the field. Visible up to 90 metres away, the lights work in low-light conditions and at night.

T 5X ships with a 1″ blue collar strap.

Specifications:
• Unit dimensions (WxHxD): 3.50″ x 1.75″ x 1.85″ (8.90 x 4.40 x 4.70 cm)
• Weight: 6.60 oz (188 g) for transmitter and antenna (without collar); 9.30 oz (265 g) total weight (with collar)
• Battery type: Rechargeable lithium-ion pack; user-replaceable
• Battery life: Up to 80 hours
• Range: 14,5 kilometres
• Interface: USB
• Water rating: 1 ATM (10 metres)
• Neck size: Minimum of 9.5″ (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: Top, orange
• LED beacon lights: Yes
• Sleep mode: Yes
• Rescue mode: Yes
• Frequency mode: MURS
• Replaceable collar straps: Yes
• Collar compatibility: 1″ (2.54 cm)
• Software updates: Via Garmin Express™ software, available for both Mac® and Windows®

Contents:
• T 5X dog device with rechargeable lithium-ion battery pack
• 1″ blue collar strap
• 18.5″ standard antenna
• 22.5″ extended-range antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Documentation

Garmin Alpha 200 & TT15 Mini Collar Package

STRONG CONNECTION. STRONG BOND. Track and train your dogs with the Alpha 200, Handheld Only system, a sunlight-readable 3.50″ capacitive touchscreen and user-friendly, six-button design.

Key Features:
• This handheld is designed to help make tracking and training simple, accessible and fast.
• Track and train your pack while they’re out in the field.
• Keep inactive dogs in the system for easier setup and management.
• Navigate every hunt with the best in Garmin mapping and sensors.
• User-replaceable battery lasts up to 20 hours.

TRACK YOUR PACK. Monitor up to 20 dogs from up to 14.50 kilometres (depending on dog device) with a 2.50-second update rate.

DOG LIST/GROUP MANAGEMENT. Keep inactive dogs in your dog list, and manage active groups so you don’t have to add and remove dogs for every hunt.

PUBLIC LAND BOUNDARIES. Optional display of public land boundaries on topographical maps helps you know that you’re venturing where you’re supposed to be.

HUNT METRICS. See each dog’s daily hunting patterns, distance and speed so you can monitor performance and help prevent overheating. Pair with TT™ 15 tracking and training collars.

SIX-BUTTON DESIGN. Use dedicated buttons for fast training cues and minor adjustments in the field.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog.

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs.

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

PRO VIEW COMPASS. The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away your dogs are, plus you will see when a dog is “Treed” or “OnPoint.”

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone.

TOPOACTIVE MAPS. Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

BIRDSEYE DIRECT. Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads, clearings and more.

NAVIGATION SENSORS. A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure, and the built-in tilt-compensated 3-axis electronic compass keeps your bearing - whether you’re moving or not.

SEE IT ALL. The sunlight-readable 3.50″ capacitive touchscreen display makes it easy to see and interact with your maps, dog data and more — even while wearing gloves.

STAY ON THE MOVE. Replaceable battery lasts up to 20 hours, giving you plenty of hunt time with your dogs in the field.

ADDITIONAL MAPPING. The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand Light and HuntView maps (each sold separately).

Specifications:
• PHYSICAL DIMENSIONS: 7.70 x 6.40 x 1.30″ (6.80 x 16.20 x 3.40 cm) *dimensions do not include antenna
• TOUCHSCREEN: Yes
• DISPLAY SIZE: 1.80″ W x 3.0″ H (4.70 x 7.70 cm); 3.50″ diag (88.90 mm)
• DISPLAY RESOLUTION: 282 x 470 pixels
• DISPLAY TYPE: Transflective, colour TFT touchscreen
• WEIGHT: 9.90 oz (280 g) with standard antenna and battery
• BATTERY TYPE: Rechargeable lithium-ion (included)
• BATTERY LIFE: Up to 20 hours
• WATER RATING: IPX7
• HIGH-SENSITIVITY RECEIVER: Yes
• INTERFACE: High-speed USB
• MEMORY/HISTORY: 16 GB
• PRODUCT NUMBER: 010-02616-53

Maps & Memory
• PRELOADED MAPS: Yes (TopoActive)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• BIRDSEYE: Yes, direct to device (no annual subscription required)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• TRACKS: Up to 20 dogs (TT 15/TT 15 mini and T5/T5 mini) and buddies (Alpha 100 and Alpha 200) simultaneously
• TRACK LOG: 20,000 points, 200 saved gpx tracks, 300 saved fit activities
• ROUTES: 250
• STORED CONTACTS: 250 dogs
• GROUP MANAGEMENT: Yes

Sensors
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Outdoor Recreation
• SUN AND MOON INFORMATION: Yes
• CUSTOM MAPS COMPATIBLE: Yes

Two-way Radio Features
• FREQUENCY BAND: MURS
• RANGE: TT 15/T5, 14.50 kilometres; TT 15 mini/T mini, 14.50 kilometres

Outdoor Applications
• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections
• WIRELESS CONNECTIVITY: Yes (Wi-Fi®, Bluetooth® and ANT+®)



The Garmin TT15 GPS mini dog tracking and training collar is the extra small dog collar for the Garmin ALPHA 100 GPS Dog system.   TT 15 mini dog device uses 18 levels of continuous and momentary stimulation, plus audible tone and vibration activated from Alpha® 100. Compatible with Astro® 430 for tracking only.

Rugged and water-resistant to 10 meters, this tracking and training dog device with collar is tough enough to run wherever your dog runs.  The stimulation features let you train each dog separately — traditional stimulation allows you to make quick changes (low, medium or high) within a predetermined stimulation level (1-6), whereas linear stimulation allows progressively more stimulation from levels 1 to 18.

You can remotely operate the LED beacon lights, built in to the dog device, to help locate your dog in low-light conditions.

Track and TRAIN up to 20 dogs (require extra TT15 mini or standard TT15 collars).     It is fully waterproof - IPX7 rating (up to 10 metres under water) and rechargeable with 4 hours fast charge battery.

Features:
Static correction, Tone, Vibration and Beacon light
The Garmin TT15 mini collar has 18 levels of continuous and momentary static correction with tone and vibration only stimulation. It also has a built-in remote operated beacon light to help pig hunters locate their dogs at night or in low light conditions. The beacon light is visible for up to 90 metres.

High-Sensitivity GPS/GLONASS Receiver
The Garmin TT15 mini collar has built in Standard GPS satellite receiver as well as the GLONASS satellite receiver. The GLONASS is the Russian Navigation Satellite System which has 24 orbital satellites. It is the second alternative navigational system in operation with GPS. It means this Garmin TT15 mini collar is able to receive 24 more satellite signals than other GPS dog tracking collars. It is very unlikely that this TT15 mini collar will lose the signal. The GLONASS helps you to locate the dog much quicker and has much better signal strength even in heavy cover.

Rescue Mode
The Rescue Mode increases the amount of time before a collar battery dies. This allows more time to find and recover the dog. This mode can be activated automatically or manually. When it is manually activated, the collar’s update rate will drop to every 2 minutes to ping the ALPHA handheld to extend the battery life. The Rescue Mode stays on until it is turned off. When the battery of the collar drops to 25%, it will be activated automatically.

Dogmaster armored mini Garmin tracking collars have the following included:

• Exclusive DogMaster Stainless Armour Kit with removable stainless steel clip - installed

• DogMasters Industrial wrap - installed

• Back up inhouse Service Dept.

Specifications:
• Stimulation/Vibration/Tone: Yes
• LED beacon lights: Yes
• Rescue mode: Yes
• Battery life: 16-30 hours - GPS mode/Standby mode
• Range: up to 6km
• Water rating: 1 ATM (10 meters)
• Unit dimensions (WxHxD): 7.8 x 4.5 x 3.5 cm
• Weight: 148g for transmitter and antenna (without collar trap); 200g total weight (with collar trap)
• Battery type: rechargeable lithium-ion pack; user replaceable
• Neck size: Minimum of 24 cm in circumference
• Interface: USB
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: top, black
• Replaceable collar straps: Yes
• Collar strap width: 2.5cm

Garmin Alpha 200 GPS & T5 Mini Collar Package

STRONG CONNECTION. STRONG BOND. Track and train your dogs with the Alpha 200, Handheld Only system, a sunlight-readable 3.50″ capacitive touchscreen and user-friendly, six-button design.

Key Features:
• This handheld is designed to help make tracking and training simple, accessible and fast.
• Track and train your pack while they’re out in the field.
• Keep inactive dogs in the system for easier setup and management.
• Navigate every hunt with the best in Garmin mapping and sensors.
• User-replaceable battery lasts up to 20 hours.

TRACK YOUR PACK. Monitor up to 20 dogs from up to 14.50 kilometres (depending on dog device) with a 2.50-second update rate.

DOG LIST/GROUP MANAGEMENT. Keep inactive dogs in your dog list, and manage active groups so you don’t have to add and remove dogs for every hunt.

PUBLIC LAND BOUNDARIES. Optional display of public land boundaries on topographical maps helps you know that you’re venturing where you’re supposed to be.

HUNT METRICS. See each dog’s daily hunting patterns, distance and speed so you can monitor performance and help prevent overheating. Pair with TT™ 15 tracking and training collars.

SIX-BUTTON DESIGN. Use dedicated buttons for fast training cues and minor adjustments in the field.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog.

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs.

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

PRO VIEW COMPASS. The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away your dogs are, plus you will see when a dog is “Treed” or “OnPoint.”

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone.

TOPOACTIVE MAPS. Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

BIRDSEYE DIRECT. Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads, clearings and more.

NAVIGATION SENSORS. A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure, and the built-in tilt-compensated 3-axis electronic compass keeps your bearing - whether you’re moving or not.

SEE IT ALL. The sunlight-readable 3.50″ capacitive touchscreen display makes it easy to see and interact with your maps, dog data and more — even while wearing gloves.

STAY ON THE MOVE. Replaceable battery lasts up to 20 hours, giving you plenty of hunt time with your dogs in the field.

ADDITIONAL MAPPING. The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand Light and HuntView maps (each sold separately).

Specifications:
• PHYSICAL DIMENSIONS: 7.70 x 6.40 x 1.30″ (6.80 x 16.20 x 3.40 cm) *dimensions do not include antenna
• TOUCHSCREEN: Yes
• DISPLAY SIZE: 1.80″ W x 3.0″ H (4.70 x 7.70 cm); 3.50″ diag (88.90 mm)
• DISPLAY RESOLUTION: 282 x 470 pixels
• DISPLAY TYPE: Transflective, colour TFT touchscreen
• WEIGHT: 9.90 oz (280 g) with standard antenna and battery
• BATTERY TYPE: Rechargeable lithium-ion (included)
• BATTERY LIFE: Up to 20 hours
• WATER RATING: IPX7
• HIGH-SENSITIVITY RECEIVER: Yes
• INTERFACE: High-speed USB
• MEMORY/HISTORY: 16 GB
• PRODUCT NUMBER: 010-02616-53

Maps & Memory
• PRELOADED MAPS: Yes (TopoActive)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• BIRDSEYE: Yes, direct to device (no annual subscription required)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• TRACKS: Up to 20 dogs (TT 15/TT 15 mini and T5/T5 mini) and buddies (Alpha 100 and Alpha 200) simultaneously
• TRACK LOG: 20,000 points, 200 saved gpx tracks, 300 saved fit activities
• ROUTES: 250
• STORED CONTACTS: 250 dogs
• GROUP MANAGEMENT: Yes

Sensors
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Outdoor Recreation
• SUN AND MOON INFORMATION: Yes
• CUSTOM MAPS COMPATIBLE: Yes

Two-way Radio Features
• FREQUENCY BAND: MURS
• RANGE: TT 15/T5, 14.50 kilometres; TT 15 mini/T mini, 14.50 kilometres

Outdoor Applications
• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections
• WIRELESS CONNECTIVITY: Yes (Wi-Fi®, Bluetooth® and ANT+®)

Garmin T5 Mini GPS Dog Collar

A top-mounted, high-sensitivity GPS/GLONASS receiver, T 5 mini dog device uses LED beacon lights activated from its compatible handheld device. The lights work in low-light conditions and at night, and are visible up to 100 yards away. The Garmin T5 Mini GPS Collar is the extra tracking only collar that will work with Alpha 100 and Astro 430 dog tracking handheld. This small dog GPS tracking collar will suits dogs from 7kg in weight. The T5 mini collar has up to 6 km range. And it is fully waterproof IPX7 rating (up to 10 metres under water), rechargeable with 4 hours fast charge (up to 30 hours per full charge).

Rugged and water-resistant to 10 meters, the tracking-only dog device with collar is tough enough to run wherever your dog runs, up to 4 miles away. T 5 mini ships with a 3/4-inch blue collar strap

Features:
• T 5 mini dog device with rechargeable lithium-ion battery
• 3/4" blue collar strap
• 18.5" standard antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Manual

Physical Specifications & Performance:
• Unit dimensions (W x H x D): 3.5" x 1.75” x 1.85" (8.9 x 4.4 x 4.7 cm); Mini: 3.1" x 1.8” x 1.4” (7.8 x 4.5 x 3.5 cm)
• Weight: 5.1 oz (145 g) for transmitter and antenna (without collar); 7.0 oz (198 g) total weight (with collar)
• Battery type: rechargeable lithium-ion pack; user replaceable
• Battery life: 16-30 hours
• Range: 4 miles
• Interface: USB
• Water rating: 1 ATM (10 meters)
• Neck size: Minimum of 9.5” (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: top, orange
• Stimulation/Vibration/Tone: No
• LED beacon lights: Yes
• Frequency band: MURS (The T 5 mini is only compatible with the Astro® 320, Astro 430 and the Alpha™ 100. T 5 mini can be configured for operation with either handheld but cannot be tracked simultaneously by both the Astro 320 and the Astro 430)
• Rescue mode: Yes
• Replaceable collar straps: Yes
• Collar compatibility: 3/4” (1.9 cm)

Montana® 750i
Rugged GPS Touchscreen Navigator with inReach® Technology and 8 Megapixel Camera

SEE THE WORLD. STAY IN TOUCH. BE THE PICTURE OF ADVENTURE.
The rugged Montana 750i handheld combines the flexibility of on- or off-road navigation with global messaging and interactive SOS via inReach satellite technology1 — plus a built-in 8-megapixel camera.

Big news. A full QWERTY keyboard lets you easily type messages.

Wander wider and still stay in touch — with inReach for messaging and 24/7 SOS.

Nav, meet cam. Put your trip pics on the map with geotags.

Routable TopoActive Australia and New Zealand maps. Now you’re free to take it off-road or on.

Meets MIL-STD 810 for thermal, shock, water and vibration.

Power your adventures with 18+ hours of lithium-ion battery life in GPS mode.

TWO-WAY MESSAGING
Exchange text messages with loved ones, post to social media, or communicate via inReach device to inReach device in the field (active satellite subscription required).

INTERACTIVE SOS
In case of emergency, trigger an interactive SOS message to GEOS, a professional 24/7 global monitoring and response center (active satellite subscription required).

GLOBAL CONNECTIVITY
Instead of relying on cellphone coverage, now your messages, SOS and tracking are transferred via the 100% global Iridium® satellite network (active satellite subscription required).

INREACH WEATHER
Available inReach weather forecast service provides detailed updates directly to your Montana handheld or paired devices, so you’ll know what to expect en route.

RUGGED BY DESIGN
This durable, water-resistant handheld is tested to U.S. military standards and features a glove-friendly 5” touchscreen that’s 50% larger than previous Montana models.

BUILT-IN CAMERA
Capture images of your exploits with Montana’s digital 8-megapixel camera. It geotags photos with coordinates, so you can navigate back to favourite sites in the future.

CITY NAVIGATOR MAPS
Seamlessly transition from trails to road navigation with preloaded City Navigator street mapping, which guides your drive with easy-to-follow turn-by-turn directions.

TOPOACTIVE AUSTRALIA AND NEW ZEALAND MAPS
To navigate your adventures, use preloaded TopoActive Australia and New Zealand maps. View elevations, coastlines, rivers, landmarks and more.

SATELLITE VIEWS
Use direct-to-device downloads of BirdsEye Satellite Imagery (no annual subscription required) to see photo-realistic views and create waypoints based on landmarks.

ABC SENSORS
Navigate your next trail with ABC sensors, including an altimeter for elevation data, barometer to monitor weather and 3-axis electronic compass.

ACTIVE WEATHER
Use cellular connectivity2 to access up-to-date Active Weather forecasts through the Garmin Connect™ app.

DOG TRACKING
For hunters and trainers, this Montana syncs with compatible Astro® or Alpha® series handhelds (sold separately) to help track sporting dogs in the field.

MULTI-GNSS SUPPORT
Access to GPS, GLONASS and GALILEO satellite networks enables Montana® 750i to track in more challenging environments than GPS alone.

TRACKING
Track your location, and share it with those at home or out in the field. They´ll be able to see your progress or ping your device for your GPS location and more via your web-based MapShare™ trip-sharing page. (Montana 700i, 750i only - satellite subscription required).

EXPEDITION MODE
Trek far and wide off-grid. Use Expedition mode, an ultralow-power GPS reference, to keep Montana tracking for a week or more between recharges.

EXTENDED BATTERY LIFE
An internal, rechargeable lithium-ion battery pack provides more than 18 hours of battery life in GPS mode.

VEHICLE MOUNTS
A variety of Montana handheld-compatible mounts (sold separately) lets you adapt your navigator for use on ATVs, boats, cars, motorcycles, RVs or other vehicles.

PHYSICAL DIMENSIONS    9.19 x 18.30 x 3.27 cm
TOUCHSCREEN
DISPLAY SIZE    6.48 x 10.80 cm; 5" diag (12.70 cm)
DISPLAY RESOLUTION    480 x 800 pixels
DISPLAY TYPE    WVGA transflective, dual orientation
WEIGHT    410 g with included lithium-ion battery pack
BATTERY TYPE    rechargeable lithium-ion (included)
BATTERY LIFE    GPS Mode: up to 18 hours
Expedition Mode: up to 330 hours
GPS Mode, 10 min Tracking: up to 18 hours
Expedition Mode, 30 min Tracking: up to 300 hours
WATER RATING    IPX7
MIL-STD-810    yes (thermal, shock, water, vibe)
HIGH-SENSITIVITY RECEIVER
INTERFACE    High speed micro USB and NMEA 0183 compatible
MEMORY/HISTORY    16 GB (user space varies based on included mapping)
PRELOADED MAPS    Yes (TopoActive Australia and New Zealand)


Garmin Alpha 10 GPS & TT15X Collar Package

The Garmin Alpha 10 is a small device with big tracking and training potential.

Key Features:
• When you’re on the move, this compact GPS device won’t weigh you down.
• Know your dog’s location, wherever the hunt takes them.
• Always on the go? Mount Alpha® 10 in your truck or anywhere else to keep it close.
• It’s up to you. Use Alpha® 10 on its own or with other dog tracking devices.
• See your dog’s location from the driver’s seat of your truck or even from your wrist.
• Stay on the hunt for longer with up to 1 week of battery life (40 hours of use).

For more flexibility on the hunt, the compact Alpha® 10 handheld can be used on its own, connected to your compatible smartphone or connected to other Garmin dog tracking devices. Map, track, sync and share from anywhere using the Garmin Explore app.

Features:

TRACK YOUR PACK. Alpha® 10 works with T5 and TT™ 15 dog devices to monitor up to 20 dogs from up to 10 kilometres with a 5-second update rate.

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track in more challenging environments than GPS alone.

HUNT-READY BATTERY LIFE. With up to a full week’s worth of battery life (40 hours of use), you’ll stay charged and ready for action, even on multiday trips.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog (when paired with select dog devices).

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs (when paired with select dog devices).

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

FOLLOW THE ACTION. Track fellow hunters by pairing Alpha® 10 with other compatible Alpha and Astro® handheld devices.

MORE WAYS TO TRACK ON THE GO. See the pack’s location from your vehicle with the Montana, Garmin DriveTrack™ 71 sat-nav — or from your wrist with your Instinct®, tactix® or fēnix® GPS watch.

Specifications:
PHYSICAL DIMENSIONS: 2.3 x 4.8 x 1.1″ (5.8 x 12.1 x 2.9 cm); dimensions do not include antenna
DISPLAY SIZE: 1.8″ (45 mm) diagonal
DISPLAY RESOLUTION: 128 x 128 pixels
DISPLAY TYPE: Sunlight-readable, monochrome, transflective memory-in-pixel (MIP)
WEIGHT: 5.6 oz (160 g) with standard antenna and spine mount attached
BATTERY TYPE: Rechargeable internal lithium-ion; nonreplaceable
BATTERY LIFE: Up to 1 week (40 hours of use)
WATER RATING: IPX7
HIGH-SENSITIVITY RECEIVER: Yes (GPS and Galileo)
INTERFACE: microUSB™
COMPASS: Yes (tilt-compensated 3-axis)
Two-way Radio Features
FREQUENCY BAND: MURS
RANGE: TT 15/T 5 = 14.5 kilometres; TT 15 mini/T 5 mini = 6.5 kilometres
COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
WIRELESS CONNECTIVITY: Yes (Bluetooth® Low Energy and ANT+®)
ADDITIONAL: Track storage, up to 10 days
PRODUCT NUMBER: 010-02290-53

The TT 15X dog tracking and training device has a top-mounted, high-sensitivity GPS and GLONASS receiver, so you can track your dog from up to 14.5 km away. Rugged and water-resistant to 10 metres (1 ATM), it’s tough enough to run wherever your dog runs. Plus, with up to 80 hours of battery life and sleep mode to remotely put the device to sleep, you can focus on the hunt instead of the next charge.

TT 15X features 18 levels of continuous and momentary stimulation plus audible tone and vibration when used with your compatible tracking and training handheld.

LED beacon lights, activated from your compatible handheld, help keep track of your dog in the field. Visible up to 90 metres away, the lights work in low-light conditions and at night.

TT 15X ships with a 1″ red collar strap.

 Specifications:
• Unit dimensions (WxHxD): 3.50″ x 1.75″ x 1.85″ (8.90 x 4.40 x 4.70 cm)
• Weight: 7.30 oz (207 g) for transmitter and antenna (without collar); 10 oz (284 g) total weight (with collar)
• Battery type: Rechargeable lithium-ion pack; user-replaceable
• Battery life: Up to 80 hours
• Range: 14,5 kilometres
• Interface: USB
• Water rating: 1 ATM (10 metres)
• Neck size: Minimum of 9.5″ (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: Top, black
• Stimulation/Vibration/Tone: Yes
• LED beacon lights: Yes
• Sleep mode: Yes
• Rescue mode: Yes
• Frequency mode: MURS
• Replaceable collar straps: Yes
• Collar compatibility: 1″ (2.54 cm)
• Software updates: Via Garmin Express™ software, available for both Mac® and Windows®

Contents:
• TT 15X dog device with rechargeable lithium-ion battery pack
• 1″ red collar strap
• 18.5″ standard antenna
• 22.5″ extended-range antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Contact point set with spanner
• Documentation

Garmin Alpha 10 GPS & TT15 Mini Collar Package

The Garmin Alpha 10 is a small device with big tracking and training potential.

Key Features:
• When you’re on the move, this compact GPS device won’t weigh you down.
• Know your dog’s location, wherever the hunt takes them.
• Always on the go? Mount Alpha® 10 in your truck or anywhere else to keep it close.
• It’s up to you. Use Alpha® 10 on its own or with other dog tracking devices.
• See your dog’s location from the driver’s seat of your truck or even from your wrist.
• Stay on the hunt for longer with up to 1 week of battery life (40 hours of use).

For more flexibility on the hunt, the compact Alpha® 10 handheld can be used on its own, connected to your compatible smartphone or connected to other Garmin dog tracking devices. Map, track, sync and share from anywhere using the Garmin Explore app.

Features:

TRACK YOUR PACK. Alpha® 10 works with T5 and TT™ 15 dog devices to monitor up to 20 dogs from up to 10 kilometres with a 5-second update rate.

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track in more challenging environments than GPS alone.

HUNT-READY BATTERY LIFE. With up to a full week’s worth of battery life (40 hours of use), you’ll stay charged and ready for action, even on multiday trips.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog (when paired with select dog devices).

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs (when paired with select dog devices).

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

FOLLOW THE ACTION. Track fellow hunters by pairing Alpha® 10 with other compatible Alpha and Astro® handheld devices.

MORE WAYS TO TRACK ON THE GO. See the pack’s location from your vehicle with the Montana, Garmin DriveTrack™ 71 sat-nav — or from your wrist with your Instinct®, tactix® or fēnix® GPS watch.

Specifications:
PHYSICAL DIMENSIONS: 2.3 x 4.8 x 1.1″ (5.8 x 12.1 x 2.9 cm); dimensions do not include antenna
DISPLAY SIZE: 1.8″ (45 mm) diagonal
DISPLAY RESOLUTION: 128 x 128 pixels
DISPLAY TYPE: Sunlight-readable, monochrome, transflective memory-in-pixel (MIP)
WEIGHT: 5.6 oz (160 g) with standard antenna and spine mount attached
BATTERY TYPE: Rechargeable internal lithium-ion; nonreplaceable
BATTERY LIFE: Up to 1 week (40 hours of use)
WATER RATING: IPX7
HIGH-SENSITIVITY RECEIVER: Yes (GPS and Galileo)
INTERFACE: microUSB™
COMPASS: Yes (tilt-compensated 3-axis)
Two-way Radio Features
FREQUENCY BAND: MURS
RANGE: TT 15/T 5 = 14.5 kilometres; TT 15 mini/T 5 mini = 6.5 kilometres
COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
WIRELESS CONNECTIVITY: Yes (Bluetooth® Low Energy and ANT+®)
ADDITIONAL: Track storage, up to 10 days
PRODUCT NUMBER: 010-02290-53


The Garmin TT15 GPS mini dog tracking and training collar is the extra small dog collar for the Garmin ALPHA 100 GPS Dog system.   TT 15 mini dog device uses 18 levels of continuous and momentary stimulation, plus audible tone and vibration activated from Alpha® 100. Compatible with Astro® 430 for tracking only.

Rugged and water-resistant to 10 meters, this tracking and training dog device with collar is tough enough to run wherever your dog runs.  The stimulation features let you train each dog separately — traditional stimulation allows you to make quick changes (low, medium or high) within a predetermined stimulation level (1-6), whereas linear stimulation allows progressively more stimulation from levels 1 to 18.

You can remotely operate the LED beacon lights, built in to the dog device, to help locate your dog in low-light conditions.

Track and TRAIN up to 20 dogs (require extra TT15 mini or standard TT15 collars).     It is fully waterproof - IPX7 rating (up to 10 metres under water) and rechargeable with 4 hours fast charge battery.

Features:

Static correction, Tone, Vibration and Beacon light
The Garmin TT15 mini collar has 18 levels of continuous and momentary static correction with tone and vibration only stimulation. It also has a built-in remote operated beacon light to help pig hunters locate their dogs at night or in low light conditions. The beacon light is visible for up to 90 metres.

High-Sensitivity GPS/GLONASS Receiver
The Garmin TT15 mini collar has built in Standard GPS satellite receiver as well as the GLONASS satellite receiver. The GLONASS is the Russian Navigation Satellite System which has 24 orbital satellites. It is the second alternative navigational system in operation with GPS. It means this Garmin TT15 mini collar is able to receive 24 more satellite signals than other GPS dog tracking collars. It is very unlikely that this TT15 mini collar will lose the signal. The GLONASS helps you to locate the dog much quicker and has much better signal strength even in heavy cover.

Rescue Mode
The Rescue Mode increases the amount of time before a collar battery dies. This allows more time to find and recover the dog. This mode can be activated automatically or manually. When it is manually activated, the collar’s update rate will drop to every 2 minutes to ping the ALPHA handheld to extend the battery life. The Rescue Mode stays on until it is turned off. When the battery of the collar drops to 25%, it will be activated automatically.

Dogmaster armored mini Garmin tracking collars have the following included:

• Exclusive DogMaster Stainless Armour Kit with removable stainless steel clip - installed

• DogMasters Industrial wrap - installed

• Back up inhouse Service Dept.

Specifications:
• Stimulation/Vibration/Tone: Yes
• LED beacon lights: Yes
• Rescue mode: Yes
• Battery life: 16-30 hours - GPS mode/Standby mode
• Range: up to 6km
• Water rating: 1 ATM (10 meters)
• Unit dimensions (WxHxD): 7.8 x 4.5 x 3.5 cm
• Weight: 148g for transmitter and antenna (without collar trap); 200g total weight (with collar trap)
• Battery type: rechargeable lithium-ion pack; user replaceable
• Neck size: Minimum of 24 cm in circumference
• Interface: USB
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: top, black
• Replaceable collar straps: Yes
• Collar strap width: 2.5cm

The Alpha 200i dog tracking and training system lets you monitor up to 20 dogs from up to 9 miles (depending on dog device) on a 3.5" display with a 2.5-second update rate. Easily control training functions by using the button-operated, dog-focused design.

You’ll also have access to premium Garmin navigation features, such as preloaded TopoActive maps, BirdsEye Satellite Imagery with direct-to-device downloads and built-in three-axis compass and barometric altimeter. Now, inReach® technology adds twoway messaging and interactive SOS alerts for peace of mind while you’re in the field.

LARGE 3.5"DISPLAY WITH SIX-BUTTON DESIGN
Features sunlight-readable 3.5" capacitive touchscreen display and a button-operated, dog-focused design for
quick, minor adjustments

TRACK YOUR PACK Monitor up to 20 dogs from up to 9 miles (depending on dog device) with a 2.5-second updaterate

DOG LIST AND GROUP MANAGEMENT Dog list and group management lets you keep inactive dogs in the system for easier setup

INREACH® TECHNOLOGY Interactive SOS alerts and two-way messaging via the 100% global Iridium® satellite network (satellite subscription
required)

MULTI-GNSS SUPPORT Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone

TOPOACTIVE MAPS Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits,
parks, coastlines, rivers, lakes and geographical points

BIRDSEYE SATELLITE IMAGERY Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads,
clearings and more

NAVIGATION SENSORS A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure,
and the built-in tilt-compensated three-axis electronic compass keeps your bearing — whether you’re moving or not

TRAINING OPTIONS (TT™ 15/ TT 15 MINIONLY) When paired with TT™ 15 tracking and training collars, you will have access to 18 levels of continuous and
momentary stimulation, plus vibration and adjustable tones

FEDERAL PUBLIC LAND BOUNDARIES
Optional display of federal public land boundaries on topographical maps shows Bureau of Land Management,
National Parks and Wilderness so you know that you’re venturing where you’re supposed to be

HUNT TIMER FUNCTION Use the convenient timer mode during hunting competitions or field trials; get quick access to the timer with the new
user-configurable buttons

PRO VIEW COMPASS The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away
your dogs are, plus you will see when a dog is “Treed” or “On Point”

GARMIN EXPLORE™ Compatible with Garmin Explore website and app to help you manage tracks, routes and waypoints and review statistics from the field

ADDITIONAL MAPPING The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand. 24K
and Garmin HuntView™ Plus maps (sold separately)

GARMIN ECOSYSTEM Track your pack from the road, your wrist and other ways, thanks to wireless connectivity with compatible Garmin
devices, such as the Garmin DriveTrack™ 71 GPS navigator, fēnix® 6 GPS watches and more

BACKWARD COMPATIBLE Backward compatible so you can keep your existing collars and other Alpha compatible devices; transfer location
data between compatible Garmin devices

LONG-LASTING BATTERY Replaceable battery lasts up to 20 hours, or up to 15 hours with inReach technology enabled

Garmin Alpha 10 GPS & T5 Mini Collar Package

The Garmin Alpha 10 is a small device with big tracking and training potential.

Key Features:
• When you’re on the move, this compact GPS device won’t weigh you down.
• Know your dog’s location, wherever the hunt takes them.
• Always on the go? Mount Alpha® 10 in your truck or anywhere else to keep it close.
• It’s up to you. Use Alpha® 10 on its own or with other dog tracking devices.
• See your dog’s location from the driver’s seat of your truck or even from your wrist.
• Stay on the hunt for longer with up to 1 week of battery life (40 hours of use).

For more flexibility on the hunt, the compact Alpha® 10 handheld can be used on its own, connected to your compatible smartphone or connected to other Garmin dog tracking devices. Map, track, sync and share from anywhere using the Garmin Explore app.

Features:

TRACK YOUR PACK. Alpha® 10 works with T5 and TT™ 15 dog devices to monitor up to 20 dogs from up to 10 kilometres with a 5-second update rate.

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track in more challenging environments than GPS alone.

HUNT-READY BATTERY LIFE. With up to a full week’s worth of battery life (40 hours of use), you’ll stay charged and ready for action, even on multiday trips.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog (when paired with select dog devices).

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs (when paired with select dog devices).

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

FOLLOW THE ACTION. Track fellow hunters by pairing Alpha® 10 with other compatible Alpha and Astro® handheld devices.

MORE WAYS TO TRACK ON THE GO. See the pack’s location from your vehicle with the Montana, Garmin DriveTrack™ 71 sat-nav — or from your wrist with your Instinct®, tactix® or fēnix® GPS watch.

Specifications:
PHYSICAL DIMENSIONS: 2.3 x 4.8 x 1.1″ (5.8 x 12.1 x 2.9 cm); dimensions do not include antenna
DISPLAY SIZE: 1.8″ (45 mm) diagonal
DISPLAY RESOLUTION: 128 x 128 pixels
DISPLAY TYPE: Sunlight-readable, monochrome, transflective memory-in-pixel (MIP)
WEIGHT: 5.6 oz (160 g) with standard antenna and spine mount attached
BATTERY TYPE: Rechargeable internal lithium-ion; nonreplaceable
BATTERY LIFE: Up to 1 week (40 hours of use)
WATER RATING: IPX7
HIGH-SENSITIVITY RECEIVER: Yes (GPS and Galileo)
INTERFACE: microUSB™
COMPASS: Yes (tilt-compensated 3-axis)
Two-way Radio Features
FREQUENCY BAND: MURS
RANGE: TT 15/T 5 = 14.5 kilometres; TT 15 mini/T 5 mini = 6.5 kilometres
COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
WIRELESS CONNECTIVITY: Yes (Bluetooth® Low Energy and ANT+®)
ADDITIONAL: Track storage, up to 10 days
PRODUCT NUMBER: 010-02290-53

A top-mounted, high-sensitivity GPS/GLONASS receiver, T 5 mini dog device uses LED beacon lights activated from its compatible handheld device. The lights work in low-light conditions and at night, and are visible up to 100 yards away. The Garmin T5 Mini GPS Collar is the extra tracking only collar that will work with Alpha 100 and Astro 430 dog tracking handheld. This small dog GPS tracking collar will suits dogs from 7kg in weight. The T5 mini collar has up to 6 km range. And it is fully waterproof IPX7 rating (up to 10 metres under water), rechargeable with 4 hours fast charge (up to 30 hours per full charge).

Rugged and water-resistant to 10 meters, the tracking-only dog device with collar is tough enough to run wherever your dog runs, up to 4 miles away. T 5 mini ships with a 3/4-inch blue collar strap

• T 5 mini dog device with rechargeable lithium-ion battery
• 3/4" blue collar strap
• 18.5" standard antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Manual

Physical Specifications & Performance

• Unit dimensions (WxHxD): 3.5" x 1.75” x 1.85" (8.9 x 4.4 x 4.7 cm); Mini: 3.1" x 1.8” x 1.4” (7.8 x 4.5 x 3.5 cm)
• Weight: 5.1 oz (145 g) for transmitter and antenna (without collar); 7.0 oz (198 g) total weight (with collar)
• Battery type: rechargeable lithium-ion pack; user replaceable
• Battery life: 16-30 hours
• Range: 4 miles
• Interface: USB
• Water rating: 1 ATM (10 meters)
• Neck size: Minimum of 9.5” (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: top, orange
• Stimulation/Vibration/Tone: No
• LED beacon lights: Yes
• Frequency band: MURS (The T 5 mini is only compatible with the Astro® 320, Astro 430 and the Alpha™ 100. T 5 mini can be configured for operation with either handheld but cannot be tracked simultaneously by both the Astro 320 and the Astro 430)
• Rescue mode: Yes
• Replaceable collar straps: Yes
• Collar compatibility: 3/4” (1.9 cm)
• Product Number: 010-01486-13

Garmin Alpha 10 GPS & T5X Collar Package

The Garmin Alpha 10 is a small device with big tracking and training potential.

Key Features:
• When you’re on the move, this compact GPS device won’t weigh you down.
• Know your dog’s location, wherever the hunt takes them.
• Always on the go? Mount Alpha® 10 in your truck or anywhere else to keep it close.
• It’s up to you. Use Alpha® 10 on its own or with other dog tracking devices.
• See your dog’s location from the driver’s seat of your truck or even from your wrist.
• Stay on the hunt for longer with up to 1 week of battery life (40 hours of use).

For more flexibility on the hunt, the compact Alpha® 10 handheld can be used on its own, connected to your compatible smartphone or connected to other Garmin dog tracking devices. Map, track, sync and share from anywhere using the Garmin Explore app.

Features:

TRACK YOUR PACK. Alpha® 10 works with T5 and TT™ 15 dog devices to monitor up to 20 dogs from up to 10 kilometres with a 5-second update rate.

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track in more challenging environments than GPS alone.

HUNT-READY BATTERY LIFE. With up to a full week’s worth of battery life (40 hours of use), you’ll stay charged and ready for action, even on multiday trips.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog (when paired with select dog devices).

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs (when paired with select dog devices).

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

FOLLOW THE ACTION. Track fellow hunters by pairing Alpha® 10 with other compatible Alpha and Astro® handheld devices.

MORE WAYS TO TRACK ON THE GO. See the pack’s location from your vehicle with the Montana, Garmin DriveTrack™ 71 sat-nav — or from your wrist with your Instinct®, tactix® or fēnix® GPS watch.

Specifications:
PHYSICAL DIMENSIONS: 2.3 x 4.8 x 1.1″ (5.8 x 12.1 x 2.9 cm); dimensions do not include antenna
DISPLAY SIZE: 1.8″ (45 mm) diagonal
DISPLAY RESOLUTION: 128 x 128 pixels
DISPLAY TYPE: Sunlight-readable, monochrome, transflective memory-in-pixel (MIP)
WEIGHT: 5.6 oz (160 g) with standard antenna and spine mount attached
BATTERY TYPE: Rechargeable internal lithium-ion; nonreplaceable
BATTERY LIFE: Up to 1 week (40 hours of use)
WATER RATING: IPX7
HIGH-SENSITIVITY RECEIVER: Yes (GPS and Galileo)
INTERFACE: microUSB™
COMPASS: Yes (tilt-compensated 3-axis)
Two-way Radio Features
FREQUENCY BAND: MURS
RANGE: TT 15/T 5 = 14.5 kilometres; TT 15 mini/T 5 mini = 6.5 kilometres
COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
WIRELESS CONNECTIVITY: Yes (Bluetooth® Low Energy and ANT+®)
ADDITIONAL: Track storage, up to 10 days
PRODUCT NUMBER: 010-02290-53

The K/T 5X dog device has a top-mounted, high-sensitivity GPS and GLONASS receiver, so you can track your dog from up to 14.5 kilometres away. It features a rugged design — water-resistant to 10 metres (1 ATM) — so it’s tough enough to run wherever your dog runs. Plus, with up to 80 hours of battery life and sleep mode to remotely put the device to sleep, you can focus on the hunt instead of the next charge.

LED beacon lights, activated from your compatible handheld, help keep track of your dog in the field. Visible up to 90 metres away, the lights work in low-light conditions and at night.

T 5X ships with a 1″ blue collar strap.

Specifications:
• Unit dimensions (WxHxD): 3.50″ x 1.75″ x 1.85″ (8.90 x 4.40 x 4.70 cm)
• Weight: 6.60 oz (188 g) for transmitter and antenna (without collar); 9.30 oz (265 g) total weight (with collar)
• Battery type: Rechargeable lithium-ion pack; user-replaceable
• Battery life: Up to 80 hours
• Range: 14,5 kilometres
• Interface: USB
• Water rating: 1 ATM (10 metres)
• Neck size: Minimum of 9.5″ (24 cm) in circumference
• High-sensitivity GPS/GLONASS receiver: Yes
• GPS antenna: Top, orange
• LED beacon lights: Yes
• Sleep mode: Yes
• Rescue mode: Yes
• Frequency mode: MURS
• Replaceable collar straps: Yes
• Collar compatibility: 1″ (2.54 cm)
• Software updates: Via Garmin Express™ software, available for both Mac® and Windows®

Contents:
• T 5X dog device with rechargeable lithium-ion battery pack
• 1″ blue collar strap
• 18.5″ standard antenna
• 22.5″ extended-range antenna
• Charging cable
• AC adapter
• Vehicle power cable
• Documentation

STRONG CONNECTION. STRONG BOND. Track and train your dogs with the Alpha 200, Handheld Only system, a sunlight-readable 3.50″ capacitive touchscreen and user-friendly, six-button design.

Key Features:
• This handheld is designed to help make tracking and training simple, accessible and fast.
• Track and train your pack while they’re out in the field.
• Keep inactive dogs in the system for easier setup and management.
• Navigate every hunt with the best in Garmin mapping and sensors.
• User-replaceable battery lasts up to 20 hours.

TRACK YOUR PACK. Monitor up to 20 dogs from up to 14.50 kilometres (depending on dog device) with a 2.50-second update rate.

DOG LIST/GROUP MANAGEMENT. Keep inactive dogs in your dog list, and manage active groups so you don’t have to add and remove dogs for every hunt.

PUBLIC LAND BOUNDARIES. Optional display of public land boundaries on topographical maps helps you know that you’re venturing where you’re supposed to be.

HUNT METRICS. See each dog’s daily hunting patterns, distance and speed so you can monitor performance and help prevent overheating. Pair with TT™ 15 tracking and training collars.

SIX-BUTTON DESIGN. Use dedicated buttons for fast training cues and minor adjustments in the field.

18 LEVELS OF STIMULATION. Momentary and continuous stimulation options let you customise training for each dog.

TONE/VIBRATION. Issue different levels of audible tone or vibration commands for quick adjustments to individual dogs.

GARMIN EXPLORE™ APP. Pair with the Garmin Explore app on your compatible smartphone to see real-time dog tracking information, save collections of dog tracks and replay tracks to see exactly what happened during your hunt.

 PRO VIEW COMPASS. The pro view compass mode gives you simple, at-a-glance tracking that shows which direction and how far away your dogs are, plus you will see when a dog is “Treed” or “OnPoint.”

MULTI-GNSS SUPPORT. Access multiple global navigation satellite systems (GPS and Galileo) to track your pack with greater accuracy than GPS alone.

TOPOACTIVE MAPS. Our preloaded TopoActive mapping provides detailed views of terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.

BIRDSEYE DIRECT. Download BirdsEye Satellite Imagery directly to the handheld for better-than-real-life views of your route, trailheads, clearings and more.

NAVIGATION SENSORS. A barometric altimeter helps you accurately monitor ascent and descent and see short-term trends in air pressure, and the built-in tilt-compensated 3-axis electronic compass keeps your bearing - whether you’re moving or not.

SEE IT ALL. The sunlight-readable 3.50″ capacitive touchscreen display makes it easy to see and interact with your maps, dog data and more — even while wearing gloves.

STAY ON THE MOVE. Replaceable battery lasts up to 20 hours, giving you plenty of hunt time with your dogs in the field.

ADDITIONAL MAPPING. The microSD™ card slot allows you to load more mapping options, such as TOPO Australia and New Zealand Light and HuntView maps (each sold separately).

Specifications:
General
• PHYSICAL DIMENSIONS: 7.70 x 6.40 x 1.30″ (6.80 x 16.20 x 3.40 cm) *dimensions do not include antenna
• TOUCHSCREEN: Yes
• DISPLAY SIZE: 1.80″ W x 3.0″ H (4.70 x 7.70 cm); 3.50″ diag (88.90 mm)
• DISPLAY RESOLUTION: 282 x 470 pixels
• DISPLAY TYPE: Transflective, colour TFT touchscreen
• WEIGHT: 9.90 oz (280 g) with standard antenna and battery
• BATTERY TYPE: Rechargeable lithium-ion (included)
• BATTERY LIFE: Up to 20 hours
• WATER RATING: IPX7
• HIGH-SENSITIVITY RECEIVER: Yes
• INTERFACE: High-speed USB
• MEMORY/HISTORY: 16 GB
• PRODUCT NUMBER: 010-02616-53
Maps & Memory
• PRELOADED MAPS: Yes (TopoActive)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• BIRDSEYE: Yes, direct to device (no annual subscription required)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• TRACKS: Up to 20 dogs (TT 15/TT 15 mini and T5/T5 mini) and buddies (Alpha 100 and Alpha 200) simultaneously
• TRACK LOG: 20,000 points, 200 saved gpx tracks, 300 saved fit activities
• ROUTES: 250
• STORED CONTACTS: 250 dogs
• GROUP MANAGEMENT: Yes

Sensors
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Outdoor Recreation
• SUN AND MOON INFORMATION: Yes
• CUSTOM MAPS COMPATIBLE: Yes

Two-way Radio Features
• FREQUENCY BAND: MURS
• RANGE: TT 15/T5, 14.50 kilometres; TT 15 mini/T mini, 14.50 kilometres

Outdoor Applications
• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections
• WIRELESS CONNECTIVITY: Yes (Wi-Fi®, Bluetooth® and ANT+®)

ROAM THE UNKNOWN
Built for every part of the journey, Overlander is the rugged, all-terrain navigator with on- and off-road navigation.

Get the lay of the land with topographic maps for Australia and New Zealand.

Or get spoken directions to the nearest coffee shop with street maps.

Share1 the plans for adventure through Garmin Explore. From your laptop to your phone to your friends.

Comes with a powered magnetic mount and a RAM ball mount. It’s not going anywhere.

Search for the nearest inspiration point while you’re in the middle of nowhere.

Need to bring your own satellite imagery? How does 64 GB of built-in storage sound?

ON AND OFF ROAD
7” colour touchscreen features turn-by-turn directions for on-road and off-road navigation covering Australia and New Zealand. Includes 64 GB internal memory to download additional TOPO maps

MILITARY STANDARD 810
Overlander is built to the U.S. military standard 810 for thermal and shock resistance. It can be mounted anywhere, thanks to the powered magnetic mount that comes with suction cup and 1” RAM ball compatible adapter.

IP5X DUST RATING
This essential piece of overlanding gear is purpose-built from the circuit board up and is designed to withstand dust and extreme temperatures.

GARMIN EXPLORE
Use the Garmin Explore app to download additional maps – such as satellite imagery and USGS quad sheets on 64 GB of internal storage – and sync all your data between devices. Easily import and export GPX files to Garmin Explore — even if offline.

FIND CAMPSITES
Overlander is preloaded with iOverlander POIs and Ultimate Public Campgrounds, so you don’t need a cell signal to route to the best-established, wild and dispersed campsites.

FIND BOUNDARIES
Overlander features preloaded topography for Australia and New Zealand. Download additional topographic maps worldwide on the 64 GB of internal storage.

KNOW YOUR VEHICLE
Customize street navigation for the size and weight of your overlanding vehicle, plus get alerts for upcoming bridge heights, weight limits, sharp curves, steep grades and more.

MULTI-GNSS SUPPORT
GPS, GLONASS and Galileo support helps track in more challenging environments than GPS alone.

NAVIGATION TOOLS
All of your overlanding equipment – such as a built-in compass, altimeter and barometer – is now in one device.TRACK RECORDER
Record your tracks, and save them to your Garmin Explore account so you can review them later on any device or share them with friends.

PITCH AND ROLL
Overlander comes with integrated pitch and roll angles to help you and your vehicle navigate difficult terrain.

INREACH® COMPATIBLE
Pair your Overlander navigator with the inReach Explorer®+, inReach SE®+ and inReach® Mini satellite communicators2 (sold separately) for two-way text messaging, interactive SOS and weather forecasts.

BACKUP CAMERA COMPATIBLE
Pair your Overlander with up to 4 of our BC™ 35 wireless backup cameras (sold separately) so you can see what’s behind you.

PHYSICAL DIMENSIONS    W x H x D 19.9 x 12.2 x 2.4 cm
DISPLAY SIZE    W x H 15.2 x 8.9 cm; 7" diagonal
DISPLAY RESOLUTION    1024 x 600 pixels
DISPLAY TYPE    Multi-touch, glass, WSVGA colour TFT with white backlight
WEIGHT    437 g
BATTERY TYPE    Rechargeable lithium-ion
BATTERY LIFE    Up to 3 hours
DROP RATING    MIL-STD-810
DUST RATING    IP5X

Keep adventurers in touch and on track, the Montana 700i handheld combines the flexibility of on- or off-road navigation with global messaging and interactive SOS via inReach satellite technology1.

Big news. A full QWERTY keyboard lets you easily type messages. Wander wider and still stay in touch — with inReach for messaging and 24/7 SOS. Routable TopoActive Australia and New Zealand maps. Now you’re free to take it off-road or on. Meets MIL-STD 810 for thermal, shock, water and vibration. Get the clear perspective of BirdsEye Satellite Imagery right to your device. Power your adventures with 18+ hours of lithium-ion battery life in GPS mode. Exchange text messages with loved ones, post to social media, or communicate via inReach device to inReach device in the field (active satellite subscription required).

Features:

• INTERACTIVE SOS
• GLOBAL CONNECTIVITY
• INREACH WEATHER
• RUGGED BY DESIGN
• CITY NAVIGATOR MAPS
• TOPOACTIVE AUS & NZ MAPS
• SATELLITE VIEWS
• ABC SENSORS
• ACTIVE WEATHER
• DOG TRACKING
• TRACKING
• EXPEDITION MODE
• EXTENDED BATTERY LIFE
• VEHICLE MOUNTS

PHYSICAL DIMENSIONS 9.19 x 18.30 x 3.27 cm
TOUCHSCREEN
DISPLAY SIZE 6.48 x 10.80 cm; 5" diag (12.70 cm)
DISPLAY RESOLUTION 480 x 800 pixels
DISPLAY TYPE WVGA transflective, dual orientation
WEIGHT 410 g with included lithium-ion battery pack
BATTERY TYPE rechargeable lithium-ion (included)
BATTERY LIFE GPS Mode: up to 18 hours
Expedition Mode: up to 330 hours
GPS Mode, 10 min Tracking: up to 18 hours
Expedition Mode, 30 min Tracking: up to 300 hours
WATER RATING IPX7
MIL-STD-810 yes (thermal, shock, water, vibe)
HIGH-SENSITIVITY RECEIVER
INTERFACE High speed micro USB and NMEA 0183 compatible
MEMORY 16 GB (user space varies based on included mapping)

GO EXPLORE THE OUTDOORS - AND STAY CONNECTED TO HOME

Make more time for adventure with this premium, rugged GPS handheld and satellite communicator. Get inReach® technology that enables two-way messaging, interactive SOS alerts and location sharing plus mapping to keep you on course.

Key Features:

• Travel longer with up to 165 hours of battery life in tracking mode and up to 425 hours in expedition mode.
• Two-way messaging lets you share the moment with the ones who matter.
• Let your loved ones follow your adventure with location tracking.
• Have an emergency? Trigger an interactive SOS alert anytime, globally.
• Track your position in challenging conditions with multi-band technology and expanded GNSS support.

Discover new favourite places.

• MULTI-BAND GNSS SUPPORT: Access multiple global navigation satellite systems (GPS, Galileo and QZSS). Get access to multiple frequencies sent by navigation satellites for improved position accuracy in areas where GNSS signals are reflected, weak or typically don't penetrate.
• ABC SENSORS: Navigate every trail with ABC sensors, including an altimeter for elevation data, barometer to monitor weather and 3-axis electronic compass.
• SATELLITE IMAGERY: Download high-resolution photorealistic maps directly to your device via Wi-Fi® technology. Easily find trails, pick stand locations and parking, create waypoints and more.
• PRELOADED TOPO MAPS: Preloaded maps show you terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.
• PREMIUM MAP FEATURES: With an Outdoor Maps+ subscription, you get public land information, landowner names, state plat maps, hunting management unit boundaries, BLM boundaries and more.
• BATTERY LIFE: Turn on expedition mode, and get up to 425 hours of battery life while using inReach technology. In the default tracking mode, you get up to 165 hours of battery life, and your device will save your location every 10 minutes.

Keep in touch on the trail.

• TWO-WAY MESSAGING: Exchange text messages with loved ones, post to social media, or communicate from inReach to inReach in the field.
• INTERACTIVE SOS ALERTS: In case of emergency, trigger an interactive SOS message to the Garmin ResponseSM centre, a 24/7-staffed professional emergency response coordination centre.
• LOCATION SHARING: Track your location and share it with those at home or out in the field. They'll be able to see your progress or ping your device for your GPS location and more.
• 100% GLOBAL IRIDIUM® SATELLITE NETWORK: Instead of relying on mobile phone coverage, now your messages, SOS alerts and tracking are transferred via the global Iridium satellite network.
• GARMIN MESSENGER™ APP: Download the Garmin Messenger app to your compatible smartphone, and pair it with your GPSMAP® 67i handheld for fast, easy messaging and 24/7 SOS that's not limited to cellphone coverage areas. The app supports group messaging as well.
• GARMIN EXPLORE™ APP: Plan, review and sync waypoints, routes and tracks by using the Garmin Explore app and website. You can even review completed activities while still in the field.
• OPTIONAL INREACH WEATHER: Use inReach connectivity to get detailed weather updates on the GPSMAP 67i handheld. Request weather forecasts for your current location, waypoints or destinations on your route.
• ACTIVE WEATHER: When connected to the Garmin Explore smartphone app , you can get real-time forecast information, so you're aware of the changing conditions.

Find your way for days.

• BUILT FOR ADVENTURE: This handheld is built to military standards for thermal, shock and water performance (MIL-STD-810), and it's even compatible with night vision goggles.
• LED FLASHLIGHT: The GPSMAP 67 series helps you keep gear to a minimum with a built-in LED flashlight that can be used as a beacon to signal for help.
• GEOCACHING: Get automatic cache updates from Geocaching Live, including descriptions, logs and hints. When connected via Wi-Fi technology or to the Garmin Explore™ smartphone app, each find will upload to your Geocaching.com profile.

Specifications

General:

• DIMENSIONS: 6.2 x 16.3 x 3.5 cm (2.5″ x 6.4″ x 1.4″)
• DISPLAY SIZE: 3.8 x 6.3 cm (1.5″W x 2.5″H ); 7.6 cm diag (3″)
• DISPLAY RESOLUTION: 240 x 400 pixels
• DISPLAY TYPE: Transflective colour TFT
• WEIGHT: 230 g with batteries
• WATERPROOF: IPX7
• BATTERY TYPE: Rechargeable, internal lithium-ion
• BATTERY LIFE: Up to 165 hours with inReach® enabled with 10 minute tracking, up to 180 hours in GPS Mode, up to 425 hours in Expedition mode with inReach enabled Up to 425 hours in expedition mode
• MIL-STD-810: Yes (thermal, shock, water); bare unit only
• INTERFACE USB-C: Yes
• MEMORY/HISTORY: 16 GB (user space varies based on included mapping)
• MANUFACTURER CODE: 010-02812-02

Maps & Memory:

• PRELOADED MAPS:  Yes (TopoActive Australia & New Zealand, routable)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes
• MAP SEGMENTS: 15,000
• SATELLITE IMAGERY: Yes (direct to device)
• INCLUDES DETAILED HYDROGRAPHIC FEATURES (COASTLINES, LAKE/RIVER SHORELINES, WETLANDS AND PERENNIAL AND SEASONAL STREAMS): Yes
• INCLUDES SEARCHABLE POINTS OF INTERESTS (PARKS, CAMPGROUNDS, SCENIC LOOKOUTS AND PICNIC SITES): Yes
• DISPLAYS NATIONAL, STATE AND LOCAL PARKS, FORESTS, AND WILDERNESS AREAS: Yes
• EXTERNAL MEMORY STORAGE: Yes (32 GB max microSD™ card)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• COURSES: 250, 200 course points per course
• TRACKS: 250
• NAVIGATION TRACK LOG: 20,000 points, 250 saved gpx tracks, 300 saved fit activities
• ACTIVITIES: Yes
• NAVIGATION ROUTES:    250, 250 points per route; 50 points auto routing

Sensors:

• HIGH-SENSITIVITY RECEIVER: Yes
• GPS: Yes
• GALILEO: Yes
• QZSS: Yes
• BEIDOU: Yes
• IRNSS: Yes
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)
• GPS COMPASS (WHILE MOVING):
• MULTI-BAND FREQUENCY:

Daily Smart Features:

• CONNECT IQ™ (DOWNLOADABLE WATCH FACES, DATA FIELDS, WIDGETS AND APPS): Yes
• SMART NOTIFICATIONS ON HANDHELD: Yes
• VIRB® REMOTE: Yes
• PAIRS WITH GARMIN CONNECT™ MOBILE: Yes
• ACTIVE WEATHER: Yes

Safety and Tracking Features:

• LIVETRACK: Yes

Outdoor Recreation:

• POINT-TO-POINT NAVIGATION: Yes
• TRACBACK®: Yes
• AREA CALCULATION: Yes
• HUNT/FISH CALENDAR: Yes
• SUN AND MOON INFORMATION: Yes
• XERO™ LOCATIONS: Yes
• GEOCACHING-FRIENDLY: Yes (Geocache Live)
• CUSTOM MAPS COMPATIBLE: Yes (500 custom map tiles)
• PICTURE VIEWER: Yes
• LED BEACON FLASHLIGHT: Yes

inReach® Features:

• INTERACTIVE SOS: Yes
• INREACH WEATHER: Yes
• SEND AND RECEIVE TEXT MESSAGES TO SMS AND EMAIL: Yes
• SEND AND RECEIVE TEXT MESSAGES TO OTHER INREACH DEVICE: Yes
• SEND AND RECEIVE GROUP MESSAGES: Yes
• EXCHANGE LOCATIONS WITH OTHER INREACH DEVICE: Yes
• MAPSHARE COMPATIBLE WITH TRACKING: Yes
• VIRTUAL KEYBOARD FOR CUSTOM MESSAGING: Yes
• SEND WAYPOINTS TO MAPSHARE DURING TRIP: Yes
• SEND ROUTE SELECTION TO MAPSHARE DURING TRIP: Yes

Outdoor Applications:

• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
• COMPATIBLE WITH GARMIN MESSENGER APP: Yes
• SMART SWITCHING BETWEEN WI-FI, MOBILE AND SATELLITE WITH GARMIN MESSENGER APP: Yes

Connections:

• CONNECTIONS WIRELESS CONNECTIVITY Yes (Wi-Fi®, Bluetooth®, ANT+®): Yes

Navigate Anywhere — Communicate Everywhere

Each Rino series device features a dual-orientation, 3-inch color touchscreen that’s glove friendly and easy to read, even in bright sunlight. A powerful 2-way radio transceiver lets you easily stay in touch with your fellow hunters, hikers or explorers in the field. You also have capability to send unit-to-unit text messages to other Rino users in your area — ideal for loud or windy conditions or when you don't want to disturb the wildlife. Rino also lets you share your waypoints, tracks, routes and geocaches wirelessly with other compatible Garmin handheld devices.

Find Your Friends
Rino series handhelds feature a unique Position Reporting capability that lets you send your exact location to other Rino users so they can see it on their map page. Plus, improved audio performance means it’s easy to communicate with any other conventional FRS/GMRS radios in the area.

Pinpoint Your Position
With its high-sensitivity GPS and GLONASS receiver and quad helix antenna, Rino 750 quickly finds your position and maintains it — even in heavy cover or remote, off-the-grid locations. Plus, a built-in barometric altimeter and 3-axis compass make it easy to get your bearings without needing to hold the unit level.

Think Rugged and Robust
Durable and water-rated to IPX7, the Rino 700 series is built to keep delivering vital mapping and tracking data, no matter what the elements throw at you. Battery life can exceed 14 hours in the field. Plus, the dual battery system lets you use the included rechargeable lithium-ion power pack or AA battery pack (sold separately).

Features:
Two-way Communication
Emergency Alert
Weather Overlays
Smart Notifcations
Barometric Altimeter
GPS / GLONASS Satellite Reception
3" Colour Touchscreen with Dual Orientation

CAST OFF CONFIDENTLY WITH A PREMIUM MARINE HANDHELD GPS
Stay on course with the GPSMAP 86i handheld. It provides all the outdoor functions and global communications of the GPSMAP® 66 series and adds on-the-water features — including wireless connectivity to your onboard marine system.

Features:

• It’s water resistant, and it floats, so it’s as at home on the water as you.
• See all your marine system info at a glance with boat data streaming.
• Cruise with peace of mind. inReach interactive SOS is there if you need it2.
• Send and receive text messages from anywhere2.
• Put convenient control of your autopilot and Fusion® systems at your fingertips.
• Stay out longer with up to 35 hours of battery life in 10-minute tracking mode.

BOAT DATA
Sync with compatible Garmin chartplotters and instruments to see real-time boat data displayed right on your handheld.

FUSION-LINK AUDIO
Get convenient remote operation of select onboard Fusion marine products.

ACCURATE TRACKING
When you’re underway, an adjustable GPS filter smooths speed and heading indications as you pass over swells for more accurate tracking.

WORLDWIDE BASEMAP
See worldwide shaded relief coverage, including oceans, seas, major lakes and rivers. And see international and state political boundaries and time zone information.

BLUECHART COVERAGE
Add optional BlueChart g3 coastal charts give you leading-edge coverage, clarity and detail with integrated Garmin and Navionics data.

AUTOPILOT REMOTE
Even when you’re not at the helm, you can control your boat. Access the autopilot app to change heading, engage pattern steering and follow a GPS route.

BACKUP NAVIGATION
Whether you’re out for a day of fishing, sailing or cruising, gain peace of mind that comes from having a backup navigator.

ABC SENSORS
Navigate anywhere with ABC sensors, including an altimeter for elevation data, barometer to monitor weather and 3-axis electronic compass.

TWO-WAY MESSAGING
The Iridium® satellite network1 lets you send and receive custom and preset text messages or emails with a delivery confirmation2.

TRIP TRACKING
Share your adventures with your web-based MapShare™ trip-sharing page so loved ones can see your progress or ping your device to see your GPS location2.

INTERACTIVE SOS
In case of emergency, trigger an interactive SOS message to the Garmin IERCC, a 24/7 staffed professional emergency response coordination centre via the 100% global Iridium satellite network.

MARINE WEATHER
Receive weather forecasts directly on your device, so you can make educated decisions based on local conditions or the destination ahead2.

Stay connected.
SMART NOTIFICATIONS
Get smart notifications right on your GPSMAP 86i handheld when you pair it with your compatible smartphone.

GARMIN EXPLORE™ APP
Sync GPSMAP 86i with Garmin Explore for cloud management of your favourite waypoints, tracks and routes.

WIRELESS CONNECTIONS
GPSMAP 86i offers Wi-Fi® connectivity, ANT+® technology and Bluetooth® wireless technology for easy wireless updates and connections.

LED FLASHLIGHT
The GPSMAP 86i helps you keep gear to a minimum with a built-in LED flashlight that can be used as a beacon to signal for help.

BATTERY LIFE
The internal, rechargeable lithium battery provides up to 35 hours of battery life in 10-minute tracking mode and up to 200 hours in expedition mode3.

In the Box:

• GPSMAP 86i handheld with worldwide basemap
• Powered mount
• Lanyard
• USB to Micro USB cable
• USB to 2 pin cable
• Mounting hardware
• Documentation

Specifications:

• DIMENSION: 2.65" x 7" x 1.7" (6.75w x 17.8h x 4.4d cm)
• DISPLAY SIZE: 1.5"W x 2.5"H (3.8 x 6.3 cm); 3" diag (7.6 cm)
• DISPLAY RESOLUTION: 240 x 400 pixels
• DISPLAY TYPE: transflective, 65K color TFT
• WEIGHT: 9.59 oz (272 g)
• WATERPROOF: IPX7
• BATTERY TYPE: rechargeable, internal lithium-ion
• BATTERY LIFE: up to 35 hours at 10-minute tracking; up to 200 hours at 30-minute tracking (power save mode)
• MIL-STD-810    yes (thermal, shock, water)
• INTERFACE    high speed microUSB and NMEA 0183 compatible
• MEMORY/HISTORY    16 GB (user space varies based on included mapping)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• MAP SEGMENTS: 15000
• SATELLITE IMAGERY: yes (direct to device)
• INCLUDES SEARCHABLE POINTS OF INTERESTS (PARKS, CAMPGROUNDS, SCENIC LOOKOUTS AND PICNIC SITES): Yes (downloadable from Garmin Express™)
• DISPLAYS NATIONAL, STATE AND LOCAL PARKS, FORESTS, AND WILDERNESS AREAS: Yes (downloadable from Garmin Express™)
• EXTERNAL MEMORY STORAGE: yes (32 GB max microSD™ card, not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 10000
• TRACKS: 250
• NAVIGATION TRACK LOG: 20,000 points, 250 saved gpx tracks, 300 saved fit activities
• NAVIGATION ROUTES: 250, 250 points per route; 50 points auto routing
• RINEX LOGGING: Yes
• HIGH-SENSITIVITY RECEIVER: Yes
• GPS: Yes
• GALILEO: Yes
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)
• GPS COMPASS (WHILE MOVING): Yes
• CONNECT IQ™ (DOWNLOADABLE WATCH FACES, DATA FIELDS, WIDGETS AND APPS): Yes
• SMART NOTIFICATIONS ON HANDHELD: Yes
• VIRB® REMOTE: Yes
• PAIRS WITH GARMIN CONNECT™ MOBILE: Yes
• ACTIVE WEATHER: Yes
• LIVETRACK: Yes
• POINT-TO-POINT NAVIGATION: Yes
• AREA CALCULATION: Yes
• HUNT/FISH CALENDAR: Yes
• SUN AND MOON INFORMATION: Yes
• XERO™ LOCATIONS: Yes
• GEOCACHING-FRIENDLY: yes (Geocache Live)
• CUSTOM MAPS COMPATIBLE: yes (500 custom map tiles)
• PICTURE VIEWER: Yes
• LED BEACON FLASHLIGHT: Yes
• INTERACTIVE SOS: Yes
• SEND AND RECEIVE TEXT MESSAGES TO SMS AND EMAIL: Yes
• SEND AND RECEIVE TEXT MESSAGES TO OTHER INREACH DEVIC: Yes
• EXCHANGE LOCATIONS WITH OTHER INREACH DEVICE: Yes
• MAPSHARE COMPATIBLE WITH TRACKING: Yes
• VIRTUAL KEYBOARD FOR CUSTOM MESSAGING: Yes
• SEND WAYPOINTS TO MAPSHARE DURING TRIP: Yes
• SEND ROUTE SELECTION TO MAPSHARE DURING TRIP: Yes
• INREACH REMOTE COMPATIBLE: Yes
• COMPATIBLE WITH GARMIN EXPLORE™ APP:  Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes
• CONNECTIONS WIRELESS CONNECTIVITY: yes (Wi-Fi®, BLUETOOTH®, ANT+®)

GO EXPLORE THE OUTDOORS.

Make more time for adventure with this premium, rugged handheld. Get long battery life and multi-band technology for enhanced accuracy plus preloaded TopoActive maps and access to satellite imagery.

Key Features:

• See your route clearly on the 3″ sunlight-readable colour display.
• Travel longer with up to 180 hours of battery life in tracking mode and up to 840 hours in expedition mode.
• Track your position in challenging conditions with multi-band technology and expanded GNSS support.
• See the terrain you’ll travel with vivid satellite imagery that downloads right to your navigator.
• Stay tuned to the forecast with active weather on your route when paired to your compatible smartphone.

Discover new favourite places.

• MULTI-BAND GNSS SUPPORT: Access multiple global navigation satellite systems (GPS, Galileo and QZSS). Get access to multiple frequencies sent by navigation satellites for improved position accuracy in areas where GNSS signals are reflected, weak or typically don't penetrate.
• ABC SENSORS: Navigate every trail with ABC sensors, including an altimeter for elevation data, barometer to monitor weather and 3-axis electronic compass.
• SATELLITE IMAGERY: Download high-resolution photorealistic maps directly to your device via Wi-Fi® technology. Easily find trails, pick stand locations and parking, create waypoints and more.
• PRELOADED TOPO MAPS: Preloaded maps show you terrain contours, topographic elevations, summits, parks, coastlines, rivers, lakes and geographical points.
• PREMIUM MAP FEATURES: With an Outdoor Maps+ subscription, you get public land information, landowner names, state plat maps, hunting management unit boundaries, BLM boundaries and more.

Find your way for days.

• BUILT FOR ADVENTURE: This handheld is built to military standards for thermal, shock and water performance (MIL-STD-810), and it's even compatible with night vision goggles.
• LED FLASHLIGHT: The GPSMAP 67 series helps you keep gear to a minimum with a built-in LED flashlight that can be used as a beacon to signal for help.
• GEOCACHING: Get automatic cache updates from Geocaching Live, including descriptions, logs and hints. When connected via Wi-Fi technology or to the Garmin Explore™ smartphone app, each find will upload to your Geocaching.com profile.
• ACTIVE WEATHER: When connected to the Garmin Explore smartphone app , you can get real-time forecast information, so you're aware of the changing conditions.
• GARMIN EXPLORE™ APP: Plan, review and sync waypoints, routes and tracks by using the Garmin Explore app and website. You can even review completed activities while still in the field.
• BATTERY LIFE: The internal lithium-ion rechargeable battery provides up to 180 hours of battery life in GPS mode and up to 840 hours in expedition mode.

Specifications

General:

• DIMENSIONS: 6.2 x 16.3 x 3.5 cm (2.5″ x 6.4″ x 1.4″)
• DISPLAY SIZE: 3.8 x 6.3 cm (1.5″W x 2.5″H ); 7.6 cm diag (3″)
• DISPLAY RESOLUTION: 240 x 400 pixels
• DISPLAY TYPE: Transflective colour TFT
• WEIGHT: 230 g with batteries
• WATERPROOF: IPX7
• BATTERY TYPE: Rechargeable, internal lithium-ion
• BATTERY LIFE: Up to 180 hours in default mode, up to 840 hours in expedition mode
• MIL-STD-810: Yes (thermal, shock, water); bare unit only
• INTERFACE USB-C: Yes
• MEMORY/HISTORY: 16 GB (user space varies based on included mapping)
• MANUFACTURER CODE: 010-02813-02

Maps & Memory

• PRELOADED MAPS:  Yes (TopoActive Australia & New Zealand, routable)
• ABILITY TO ADD MAPS: Yes
• BASEMAP: Yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes
• MAP SEGMENTS: 15,000
• SATELLITE IMAGERY: Yes (direct to device)
• INCLUDES DETAILED HYDROGRAPHIC FEATURES (COASTLINES, LAKE/RIVER SHORELINES, WETLANDS AND PERENNIAL AND SEASONAL STREAMS): Yes
• INCLUDES SEARCHABLE POINTS OF INTERESTS (PARKS, CAMPGROUNDS, SCENIC LOOKOUTS AND PICNIC SITES): Yes
• DISPLAYS NATIONAL, STATE AND LOCAL PARKS, FORESTS, AND WILDERNESS AREAS: Yes
• EXTERNAL MEMORY STORAGE: Yes (32 GB max microSD™ card)
• WAYPOINTS/FAVORITES/LOCATIONS: 10,000
• COURSES: 250, 200 course points per course
• TRACKS: 250
• NAVIGATION TRACK LOG: 20,000 points, 250 saved gpx tracks, 300 saved fit activities
• ACTIVITIES: Yes
• NAVIGATION ROUTES:  250, 250 points per route; 50 points auto routing

Sensors

• HIGH-SENSITIVITY RECEIVER: Yes
• GPS: Yes
• GLONASS: Yes
• GALILEO: Yes
• QZSS: Yes
• BEIDOU: Yes
• IRNSS: Yes
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)
• GPS COMPASS (WHILE MOVING): Yes
• MULTI-BAND FREQUENCY: Yes

Daily Smart Features

• CONNECT IQ™ (DOWNLOADABLE WATCH FACES, DATA FIELDS, WIDGETS AND APPS): Yes
• SMART NOTIFICATIONS ON HANDHELD: Yes
• VIRB® REMOTE: Yes
• PAIRS WITH GARMIN CONNECT™ MOBILE: Yes
• ACTIVE WEATHER: Yes

Safety and Tracking Features

• LIVETRACK: Yes

Outdoor Recreation

• POINT-TO-POINT NAVIGATION: Yes
• TRACBACK®: Yes
• AREA CALCULATION: Yes
• HUNT/FISH CALENDAR: Yes
• SUN AND MOON INFORMATION: Yes
• XERO™ LOCATIONS: Yes
• GEOCACHING-FRIENDLY: Yes (Geocache Live)
• CUSTOM MAPS COMPATIBLE: Yes (500 custom map tiles)
• PICTURE VIEWER: Yes
• LED BEACON FLASHLIGHT: Yes

inReach® Features

• INREACH REMOTE COMPATIBLE: Yes

Outdoor Applications

• COMPATIBLE WITH GARMIN EXPLORE™ APP: Yes
• GARMIN EXPLORE WEBSITE COMPATIBLE: Yes

Connections

• CONNECTIONS WIRELESS CONNECTIVITY Yes (Wi-Fi®, Bluetooth®, ANT+®): Yes

The Garmin Pro 550 Dog Training System provides intuitive, 1-handed training for up to 3 Dogs.

Handheld Tracking System for Sporting Dogs

With faster 2.5-second location updates and the capacity to follow up to 20 dogs¹, Astro 430 is a handheld powerhouse of dog-tracking performance. Intuitive and easy to use, the Astro 430 handheld features a vibrant 2.6-inch color display, preloaded TOPO Lite AU/NZ mapping, an optional in-unit rechargeable battery and Hunt Metrics data to help analyse your dogs’ tracking habits in the field, so you can know how to train more effectively.

Key Features:

• Track up to 20 dogs at a time, with ranges up to 9 miles using a Garmin T 5 collar device
• 2.5-second update rate provides faster location tracking when dogs are on the run
• GPS/GLONASS reception enables better satellite tracking in challenging environments than GPS alone
• Comes with preloaded TOPO Lite AU/NZ mapping; compatible with Garmin HuntView cards
• Hunt Metrics data helps analyse your dogs’ hunting patterns and behaviors; view distance traveled, time afield and more

Follow Your Dog's Every Move

Using the Garmin T 5 collar devices² (sold separately) to transmit each dog’s location as often as every 2.5 seconds, Astro 430 is quick to pinpoint the track they’re following — even when they’re on the run. On the Astro’s bright, crisp display, you can see your dog’s current location and a trail of where he’s been. You also can switch over to the Dog Track page to view a compass pointing to your dog’s location. For help in keeping the big picture in sight when tracking multiple dogs, it’s easy to auto zoom the map page, so all dogs can be seen on the display at any time. Dogs that are too far away to fit on the map’s current zoom scale can be notated on the display’s margin in the direction of the dog’s location. To reduce visual clutter on the map, you can toggle between “show all,” “show some” and “show none” — selecting the duration that each dog’s track is viewable on the display. You can also share a dog’s track code so another person can view your dog’s location on their unit’s map, along with the dog tracking compass. Further, by sharing a dog’s control code, you can allow another person to configure and control your dog’s on-collar device.

See More Detail with Additional Mapping

Astro 430 features a microSD™ card slot that allows you to load even more mapping options, such as TOPO Lite AU/NZ and HuntView maps (sold separately). You also can opt for City Navigator AU/NZ map data that gives you turn-by-turn driving directions on roads.

Astro 430 is also compatible with Garmin Custom Maps, free software that transforms paper and electronic maps into downloadable maps for your device.

Track with Hunt Metrics Data

Sophisticated Hunt Metrics help monitor your dog’s hunting patterns and behaviors to optimize your training opportunities. You can see your dog's times, distances traveled and overall scores. Plus, the Astro 430 will also capture the number of times during the hunt when an “on point” or “treed” event was indicated.

Count Your Coveys

After you’ve tracked down your quarry, mark the exact spot with Astro’s Covey Counter™, a special waypoint that shows the exact location, time of day and elevation where you found your prey as well as the number of birds you flushed and took from that location. Astro lets you save other special waypoints, such as “Truck” and “Lodge,” so you can easily find your way back to these locations at the end of the hunt. Astro also offers special waypoint icons to represent food plots, tree stands and other hunting-related points.

Share Wirelessly

With an expanded ecosystem of wireless connectivity options, Astro 430 can support unit-to-unit data transfer with a variety of compatible Garmin devices. For example, the outdoor Garmin DriveTrack™ 70 GPS navigator can receive and display dog positions on its moving map — with TOPO or satellite image views — showing navigation cues to your dog’s current location. Likewise, fēnix® 3 GPS watches can receive dog status updates and alerts for viewing at a glance on your wrist. Also, while you’re in the field, Astro 430 lets you link and share wirelessly with your buddies’ compatible devices, such as the Oregon® handheld, Montana® handheld, GPSMAP® 64 chartplotter or other ANT+^® enabled devices, to help coordinate hunt logistics on the go.

Turn Your Computer Into a BaseStation for Tracking Dogs

Load your laptop with BaseStation software to turn it into a field control center for tracking multiple dogs (equipped with T 5 dog devices²). View real-time GPS information on the larger display of your computer, making it ideal for canine search and rescue teams. And because it’s GPS/GLONASS capable, you'll get tracking, even where Internet and cell phone service isn’t available.

Tough, Water-resistant, Long-lasting

Like all Garmin outdoor products, Astro 430 is designed to be effective, easy to use, reliable and rugged enough to withstand all the blows, bumps and sloppy conditions of training and hunting. The handheld unit is water-resistant to IPX7, and it can be powered with standard AA batteries — or it’s optionally available with a long-lasting NiMH battery pack that’s rechargeable in the unit. What’s more, if you ever drop or misplace your Astro 430 in the field, the high-visibility orange case makes it easy to track down.

Specifications:

General

• DIMENSION: 2.4" x 6.3" x 1.4" (6.1 x 16.0 x 3.6 cm)
• DISPLAY SIZE: 1.43" x 2.15" (3.6 x 5.5 cm); 2.6" diag (6.6 cm)
• DISPLAY RESOLUTION: 160 x 240 pixels
• DISPLAY TYPE: transflective, 65-K color TFT
• WEIGHT: 9.2 oz (260.1 g) with batteries
• WATERPROOF: IPX7
• BATTERY TYPE: Optional NiMH pack or 2 standard AA (not included)
• BATTERY LIFE: up to 20 hours (Astro 430)
• MEMORY/HISTORY: 4 GB

Maps & Memory

• PRELOADED MAPS: yes (TOPO)
• ABILITY TO ADD MAPS: yes
• BASEMAP: yes
• AUTOMATIC ROUTING (TURN BY TURN ROUTING ON ROADS) FOR OUTDOOR ACTIVITIES: Yes (with optional mapping for detailed roads)
• EXTERNAL MEMORY STORAGE: microSD™ card (not included)
• WAYPOINTS/FAVORITES/LOCATIONS: 2000
• NAVIGATION TRACK LOG: 10,000 points, 200 saved tracks
• NAVIGATION ROUTES: 200

Sensors

• HIGH-SENSITIVITY RECEIVER: Yes
• BAROMETRIC ALTIMETER: Yes
• COMPASS: Yes (tilt-compensated 3-axis)

Outdoor Recreation

• AREA CALCULATION: Yes
• HUNT/FISH CALENDAR: Yes
• SUN AND MOON INFORMATION: Yes
• GEOCACHING-FRIENDLY: Yes (Paperless)
• CUSTOM MAPS COMPATIBLE: Yes

Additional

• Range (line of sight): T Series: 9 miles; T mini Series: 4 miles
• Frequency band: The T Series and the TT Series dog collars cannot be tracked simultaneously by both the Astro 320 and Astro 430.
• Handhelds vibration mode: yes
• Tracks up to 20 dogs simultaneously

Manufacturer code: 010-01635-53

Included:

• Astro 430 handheld
• 5" standard and 13" extended range antennas
• Belt clip
• USB cable
• Documentation
